Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
65
STR-KM5/KM7
* C2884 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V
C2901 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2905 1-126-210-21 ELECT CHIP 220uF 20% 4V
C2906 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2908 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2909 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2910 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2912 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2913 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2914 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2917 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2918 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2920 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2921 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2922 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2923 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2958 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2961 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2962 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2963 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2964 1-100-381-11 ELECT CHIP 10uF 20% 16V
C2965 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2966 1-100-381-11 ELECT CHIP 10uF 20% 16V
C2967 1-100-912-11 CERAMIC CHIP 1uF 10% 25V
C2968 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2969 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C2970 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2971 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C2972 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2973 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2974 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2975 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2976 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2977 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2978 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN2103 1-842-642-11 CONNECTOR, BOARD TO BOARD 12P
CN2104 1-842-652-11 CONNECTOR, BOARD TO BOARD 14P
CN2105 1-842-652-11 CONNECTOR, BOARD TO BOARD 14P
CN2501 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN2502 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN2503 1-820-115-41 CONNECTOR, FFC/FPC 15P
CN2504 1-817-097-21 PIN, CONNECTOR (1.5MM) (SMD) 13P
CN2505 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN2506 1-785-125-21 CONNECTOR 6P
CN2508 1-820-119-41 CONNECTOR, FFC/FPC 21P
CN2509 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D2003 8-719-049-09 DIODE 1SS367-T3SONY
D2004 8-719-049-09 DIODE 1SS367-T3SONY
D2018 8-719-049-09 DIODE 1SS367-T3SONY
D2019 6-502-961-01 DI DA2J10100L
D2104 6-502-961-01 DI DA2J10100L
D2110 6-502-961-01 DI DA2J10100L
D2302 6-500-335-01 DIODE MC2838-T112-1
D2303 6-500-335-01 DIODE MC2838-T112-1
D2714 8-719-053-18 DIODE 1SR154-400TE-25
D2715 8-719-049-09 DIODE 1SS367-T3SONY
D2716 8-719-049-09 DIODE 1SS367-T3SONY
D2717 6-502-961-01 DI DA2J10100L
D2719 8-719-049-09 DIODE 1SS367-T3SONY
D2720 8-719-049-09 DIODE 1SS367-T3SONY
D2721 8-719-049-09 DIODE 1SS367-T3SONY
D2722 8-719-053-18 DIODE 1SR154-400TE-25
D2723 8-719-053-18 DIODE 1SR154-400TE-25
D2724 6-502-961-01 DI DA2J10100L
D2725 6-502-961-01 DI DA2J10100L
D2729 6-503-012-01 DI DZ2J04300L
D2730 8-719-060-48 DIODE RB751V-40TE-17
< RESISTOR/FERRITE BEAD >
FB2031 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2032 1-218-951-11 METAL CHIP 680 5% 1/16W
FB2033 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2043 1-400-862-11 BEAD, FERRITE
FB2101 1-400-862-11 BEAD, FERRITE
FB2311 1-400-862-11 BEAD, FERRITE
FB2501 1-400-862-11 BEAD, FERRITE
FB2502 1-400-862-11 BEAD, FERRITE
FB2603 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2604 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2608 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2801 1-500-445-21 FERRITE, EMI (SMD) (2012)
* FB2884 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB2885 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2889 1-400-862-11 BEAD, FERRITE
FB2890 1-400-862-11 BEAD, FERRITE
FB2891 1-400-862-11 BEAD, FERRITE
FB2892 1-400-862-11 BEAD, FERRITE
FB2893 1-400-862-11 BEAD, FERRITE
FB2894 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2896 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB2898 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2899 1-500-445-21 FERRITE, EMI (SMD) (2012)
< IC >
IC2007 6-718-383-01 IC TC74VHC393FT (ELK)
IC2009
8-759-698-31 IC TC7WH74FK
IC2010 6-717-680-01 IC BD00IC0WEFJ-E2
IC2019 6-712-397-01 IC 74AHC1G08GW-125
IC2020 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC2032 6-707-870-01 IC TC74VHC157FT (EKJ)
IC2033 6-709-861-01 IC TC7SH126FU
IC2034 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC2036 (Not supplied) IC 74AHC595PW-118
IC2105 6-715-079-01 IC MB90F058PF-G-NNE1
IC2106 6-717-889-01 IC M24C64-WMN6T (C)
IC2107 6-705-468-01 IC BA33BC0FP-E2
IC2123 6-711-874-01 IC WM8768GEDS/R
IC2303 6-709-888-01 IC TC7WHU04FK
IC2351 6-600-827-01 IC JSR1124 (DIGITAL OPTICAL GAME IN)
IC2352 6-600-827-01 IC JSR1124 (DIGITAL OPTICAL SAT/CATV IN)
IC2421 6-705-337-01 IC TK11150CSCL-G
IC2801 6-717-938-01 IC ADSST-AVR-3025
IC2802 A-1852-602-A IC W25Q80BVSSIG (for SERVICE) (KM7)
IC2802 A-1852-606-A IC W25Q80BVSSIG (for SERVICE) (KM5)
IC2804 6-707-870-01 IC TC74VHC157FT (EKJ)
IC2805 6-707-863-01 IC TC74VHC08FT (EKJ)
DIGITAL AUDIO
Ver. 1.6
Note:
IC2036 on the DIGITAL AUDIO board cannot exchange
with single. When this part on the DIGITAL AUDIO board is
damaged, exchange the entire mounted board.
