STR-KS360/KS360S
45
Pin No. Pin Name I/O Description
125 SPICLK I Serial data transfer clock signal input from the system controller
126 MISO O Serial data output to the main system controller
127 MOSI I Serial data input from the main system controller
128 GND - Ground terminal
129 VDDINT - Power supply terminal (+1.2V)
130 VDDEXT - Power supply terminal (+3.3V)
131 AVDD - Power supply terminal (+1.2V)
132 AVSS - Ground terminal
133 GND - Ground terminal
134 CLKOUT O Local clock signal output terminal Not used
135
EMU∗
O Emulation status output terminal Not used
136 TDO O Test data output terminal Not used
137 TDI I Test data input terminal Not used
138
TRST∗
I Test reset signal input terminal Not used
139 TCK I Test clock signal input terminal Not used
140 TMS I Test mode selection signal input terminal Not used
141 GND - Ground terminal
142 CLKIN I System clock input terminal (25 MHz)
143 XTAL O System clock output terminal (25 MHz)
144 VDDEXT - Power supply terminal (+3.3V)
