STR-KS360/KS360S
46
Pin No. Pin Name I/O Description
1 DAMP_SCDT/DIR_DIN O Serial data output to the digital audio interface receiver and stream processor
2
DAMP_SHIFT/
DIR_DINCLK
O
Serial data transfer clock signal output to the digital audio interface receiver and stream
processor
3 CEC_DI I CEC serial data input from the HDMI connector
4 SIRCS_IN I SIRCS signal input from the remote control receiver
5 DSP_MOSI O Serial data output to the DSP
6 DSP_MISO I Serial data input from the DSP
7 DSP_SPICLK O Serial data transfer clock signal output to the DSP
8 BYTE I External data bus width selection signal input terminal “L”: 16 bit Fixed at “L” in this set
9 CNVss I
Processor mode selection signal input terminal “L”: single chip mode
Fixed at “L” in this set
10 DIR_XSTATE I Clock change status input from the digital audio interface receiver
11 DCACONOFF I
Calibration microphone connection detection signal input terminal
“H”: calibration microphone is connected
12 RESET I
System reset signal input from the reset signal generator “L”: reset
For several hundreds msec. after the power supply rises, “L” is input, then it change to “H”
13 Xout O Main system clock output terminal (5 MHz)
14 Vss - Ground terminal
15 Xin I Main system clock input terminal (5 MHz)
16 Vcc1 - Power supply terminal (+3.3V)
17 NMI I Non-maskable interrupt signal input terminal Not used
18 DIR_ZERO I Zero data detection signal input from the digital audio interface receiver
19 DIR CSFLAG I Channel status 48 head bit update fl ag input from the digital audio interface receiver
20 DRIVE_OPC(DIAG) I Shut down signal input from the power amplifi er “L”: shut down
21 PCM_MULTI O DSP input data selection signal output terminal “L”: A/D converter data , “H”: LPCM data
22 CEC_DO O CEC serial data output to the HDMI connector
23 PCONT2 O Power supply on/off control signal output terminal “H”: power on
24 DIR_HCE O Chip enable signal output to the digital audio interface receiver
25 NO USE O Not used
26 DSP SPIDS O Device selection signal output to the DSP
27 DIR EEROR I Error detection signal input from the digital audio interface receiver “H”: error
28 NO USE O Not used
29 I2C_CLK I/O Two-way I2C clock bus terminal Not used
30 I2C_DATA I/O Two-way I2C data bus terminal Not used
31 UCOM TX-DMP RX O Serial data output to the DMPORT connector
32 UCOM RX-DMP TX I Serial data input from the DMPORT connector
33 CLK1 O Not used
34 S-AIR_SRC_MUTE O
Sampling rate converter muting signal output to the wireless transmitter (EZW-T100)
(KS360S only)
35 UCOM TX-HDMI RX O Serial data output to the HDMI controller
36 UCOM RX-HDMI TX I Serial data input from the HDMI controller
37, 38 NO USE O Not used
39 PCONT3_SAIR O
Power supply on/off control signal output terminal for wireless transmitter (EZW-T100)
“H”: power on (KS360S only)
40 ST_CE O Chip enable signal output to the tuner (FM/AM)
41 ST_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
42 RDS_DATA I RDS serial data input from the tuner (FM/AM) (KS360S: AEP and UK models only)
43 ST_DI I Serial data input from the tuner (FM/AM)
44 TUNED I Tuned detection signal input from the tuner (FM/AM) “L”: tuned
45 ST_DO O Serial data output to the tuner (FM/AM)
46 DC_DET I Over load detection signal input terminal “L”: over load
47 PCONT4_DSP O Power supply on/off control signal output terminal for DSP “H”: power on
48 HDMI_MUTE O HDMI muting control signal output terminal
49 VOL_DOWN_A I Jog dial pulse signal input from the rotary encoder (A phase input) (for MASTER VOLUME)
50 PCONT1 O Power supply on/off control signal output terminal “H”: power on
51 TC74VHC153A O Digital audio input signal selection signal output terminal
MAIN BOARD IC1005 R5F3640MDFAR (SYSTEM CONTROLLER)
