STR-KS360/KS360S
47
Pin No. Pin Name I/O Description
52 VOLUME_UP I Jog dial pulse signal input from the rotary encoder (B phase input) (for MASTER VOLUME)
53 ROM_SDA I/O Two-way I2C data bus with the EEPROM
54 ROM_SCL O I2C clock signal output to the EEPROM
55, 56 NO USE O Not used
57 FL_CLK O Serial data transfer clock signal output to the fl uorescent indicator tube driver
58 CEC_STBY_LED O LED drive signal output terminal for ACTIVE STANDBY indicator “H”: LED on
59 FL_LAT O Chip select signal output to the fl uorescent indicator tube driver
60 FL_D_OUT O Serial data output to the fl uorescent indicator tube driver
61 NO USE O Not used
62 Vcc2 - Power supply terminal (+3.3V)
63 S-AIR RST O Reset signal output to the wireless transmitter (EZW-T100) (KS360S only)
64 Vss - Ground terminal
65 NO USE O Not used
66 TC74VHC153B O Digital audio input signal selection signal output terminal
67 S-AIR GPIO2 I Interrupt signal input from the wireless transmitter (EZW-T100) (KS360S only)
68 DSP_INTR I Interrupt request signal input from the DSP
69 DIR RST O Reset signal output to the digital audio interface receiver
70 SAIR_ADC_SEL O
A/D converter selection signal output to the wireless transmitter (EZW-T100)
(KS360S only)
71 S-AIR_DET I
Wireless transmitter (EZW-T100) connection detection signal input terminal
“L”: wireless transmitter (EZW-T100) is connected (KS360S only)
72 DAMP_SOFT_MUTE O Soft muting on/off control signal output to stream processor “L”: muting on
73 AC_CUT I AC cut detection signal input terminal “L”: AC cut
74 POWER KEY I Wake-up signal (by power switch input) input terminal
75 RDS_CLK I
RDS serial data transfer clock signal input from the tuner (FM/AM)
(KS360S: AEP and UK models only)
76 DAMP_INIT O Reset signal output to the stream processor “L”: reset
77 S-AIR_I2C_SDA I/O Two-way I2C data bus with the wireless transmitter (EZW-T100) (KS360S only)
78 S-AIR_I2C_SCL I/O Two-way I2C clock bus with the wireless transmitter (EZW-T100) (KS360S only)
79, 80
DAMP_LATCH2,
DAMP_LATCH3
O Serial data latch pulse signal output to the stream processor
81 DRIVE_RST(EN) O Reset signal output to the power amplifi er “H”: reset
82 DAMP_LATCH1 O Serial data latch pulse signal output to the stream processor
83, 84
OVERFLOW1,
OVERFLOW2
I Overfl ow detection signal input from the stream processor “L”: overfl ow
85 SAIR_SEL O
Wireless transmitter (EZW-T100) output signal selection signal output terminal
(KS360S only)
86 BD3842DATA O Serial data output to the analog audio input selector
87 BD3842CLK O Serial data transfer clock signal output to the analog audio input selector
88 DSP_RST O Reset signal output to the DSP “L”: reset
89 NO USE O Not used
90 KEY_0 I Power switch input terminal
91 DMPORT_DET I
Digital media port adapter connection detection signal input terminal
“L”: digital media port adapter is connected
92 DESTINATION I Destination setting terminal
93 MODEL I Model setting terminal
94 HDMI_RST O Reset signal output to the HDMI controller “L”: reset
95 AD KEY I INPUT SELECTOR switch input terminal
96 AVss - Ground terminal
97 PCONT_HDMI O Power supply on/off control signal output terminal for HDMI section “H”: power on
98 Vref I Reference voltage (+3.3V) input terminal
99 AVcc - Power supply terminal (+3.3V)
100 DIR_HDOUT I Serial data input from the digital audio interface receiver
