STR-KS360/KS360S
48
HDMI BOARD IC3511 SII9013CLU (HDMI RECEIVER)
Pin No. Pin Name I/O Description
1 VSYNC O Vertical synchronize signal output for the HDMI transmitter
2 to 5 QO23 to QO20 - Not used
6 IOGND - Ground terminal
7 IOVCC - Power supply terminal (+3.3V)
8 to 11 QO19 to QO16 - Not used
12 CVCC18 - Power supply terminal (+1.8V)
13 CGND - Ground terminal
14 to 17 QO15 to QO12 - Not used
18 IOGND - Ground terminal
19 IOVCC - Power supply terminal (+3.3V)
20 to 23 QO11 to QO8 - Not used
24 CVCC18 - Power supply terminal (+1.8V)
25 CGND - Ground terminal
26 to 29 QO7 to QO4 - Not used
30 IOGND - Ground terminal
31 IOVCC - Power supply terminal (+3.3V)
32 to 35 QO3 to QO0 - Not used
36 CVCC18 - Power supply terminal (+1.8V)
37 CGND - Ground terminal
38 CI2CA - Not used
39 CSDA I/O I2C two-way data bus with the EEPROM, HDMI transmitter and HDMI controller
40 CSCL I I2C clock signal input from the HDMI controller
41 DSDA I/O I2C two-way data bus with the HDMI input selector and EEPROM
42 DSDL I I2C clock signal input from the HDMI input selector
43 NC - Not used
44 PWR5V I Power supply voltage (+5V) input from the HDMI connector
45 CVCC18 - Power supply terminal (+1.8V)
46 PGND - Ground terminal
47 PVCC - Power supply terminal (+3.3V)
48 PSVD - Not used
49 AVCC - Power supply terminal (+3.3V)
50 RXC- I TMDS clock signal input from the HDMI input selector
51 RXC+ I TMDS clock signal input from the HDMI input selector
52 AGND - Ground terminal
53 AVCC - Power supply terminal (+3.3V)
54 RX0- I TMDS data input from the HDMI input selector
55 RX0+ I TMDS data input from the HDMI input selector
56 AGND - Ground terminal
57 AVCC - Power supply terminal (+3.3V)
58 RX1- I TMDS data input from the HDMI input selector
59 RX1+ I TMDS data input from the HDMI input selector
60 AGND - Ground terminal
61 AVCC - Power supply terminal (+3.3V)
62 RX2- I TMDS data input from the HDMI input selector
63 RX2+ I TMDS data input from the HDMI input selector
64, 65 AGND, DGND - Ground terminal
66 DVCC18 - Power supply terminal (+1.8V)
67 MUTE O HDMI muting control signal output terminal
68 IOVCC - Power supply terminal (+3.3V)
69 IOGND - Ground terminal
70 SPDIF O SPDIF signal output to the digital audio interface receiver and HDMI transmitter
71 to 74 SD3 to SD0 O Serial data output to the DSP and HDMI transmitter
75 WS O L/R sampling clock signal output to the DSP and HDMI transmitter
76 SCK O Bit clock signal output to the DSP and HDMI transmitter
