Front Panel Descriptions
SECTION 1
GENERAL
Location of Parts and Controls
1 PROTECTION indicator
2 U (Power) button
3 Remote sensor
4 TAPE 1/DAT indicator
5 TAPE 2/MD indicator
6 AUX indicator
7 CD indicator
8 TUNER indicator
9 PHONO indicator
10 INPUT SELECTOR knob
11 VOLUME knob
12 SUBSONIC button
13 SOURCE indicator
14 SOURCE DIRECT button and indicator
15 LOUDNESS button
16 TAPE MONITOR knob
17 BALANCE knob
18 TREBLE knob
19 BASS knob
20 SPEAKERS knob
21 PHONE jack
22 EON LINK button
23 EON LINK indicator
