Sony Trimaster PVM-2541A User Manual

Adjustment Using the Menus
31
CLOSED CAPTION SETTING
AUDIO SETTING
Submenu Setting
CLOSED CAP. Select ON to display closed caption
and OFF not to display.
TYPE Sets the closed caption display
type.
• AUTO1: Select this to display
automatically 608(VBI)*
3
when SD-SDI signal is
input, or to display
automatically 708*
1
when
HD-SDI signal is input.
• AUTO2: Select this to display
automatically 608(VBI)*
3
when SD-SDI signal is
input, or to display
automatically 608(708)*
2
when HD-SDI signal is
input.
• 708: Select this to display 708*
1
when HD-SDI signal is
input.
• 608(708): Select this to display
608(708)*
2
when HD-SDI
signal is input.
• 608(VBI): Select this to display
608(VBI)*
3
when SD-SDI
signal is input.
*1 708 is a closed caption signal
conforming to the EIA/CEA-
708 standard.
*2 608(708) is a closed caption
signal conforming to the EIA/
CEA-608 standard, and which is
transmitted as EIA/CEA-708
standard.
*3 608(VBI) is a closed caption
signal conforming to the EIA/
CEA-608 standards, and which
is transmitted as Line 21.
708 Sets the closed caption type for
708. Select from SERVICE1 to
SERVICE6.
608 Sets the closed caption type for
608(708) and 608(VBI). Select
from CC1, CC2, CC3, CC4,
TEXT1, TEXT2, TEXT3 and
TEXT4.
CLOSED CAP.: xxx
TYPE: xxx
708: xxx
608: xxx
CAPTION LEVEL: xxxx
USER CONFIG – CLOSED CAPTION SETTING
CAPTION LEVEL Sets the luminance of the displayed
characters. Select LOW or HIGH.
Note
You can change the setting only
when SDI signal is input.
Submenu Setting
SDI AUDIO SETTING Sets the audio channel when SDI
signal is input.
• 3G/HD/SD: Selects from among
channels CH1 to CH16, odd
channel + even channel
(CH1+CH2,
CH3+CH4···CH15+CH16)
and OFF.
You can display the L/R audio
levels of the selected channels. (see
WFM/ALM/VECTOR (waveform
monitor, audio level meter, and
vectorscope) SETTING on
page 27).
• SPEAKER OUTPUT: Select an
audio format to output from
speakers, headphone jack,
and AUDIO OUT
connector.
EMBEDDED: Outputs an
audio signal embedded in
SDI.
ANALOG: Outputs an
audio signal that comes from
the AUDIO IN connector.
Note
The SDI audio signal is compatible
only with 24 bit.
Submenu Setting
SDI AUDIO SETTING:
3G/HD/SD: xxx
SPEAKER OUTPUT: xxxxxx
USER CONFIG – AUDIO SETTING
