Sony TRINITRON CPD-520GS - Timing Specification

CPD-520GS/520GST/520GST9
– 4 –
MODE TEST MODE
MODE AT PRODUCTION MODE 1 MODE 2
RESOLUTION 738 X 414 1600 X 1200
CLOCK 28.322 MHZ 202.500 MHZ
— HORIZONTAL —
H-FREQ 31.469 kHz 93.750 kHz
usec usec
H. TOTAL 31.777 10.667
H. BLK 5.720 2.765
H. FP 0.318 0.316
H. SYNC 3.813 0.948
H. BP 1.589 1.501
H. ACTIV 26.057 7.901
— VERTICAL —
V. FREQ(HZ) 70.087Hz 75.000 Hz
lines lines
V. TOTAL 449 1250
V. BLK 35 50
V. FP 5 1
V. SYNC 2 3
V. BP 28 46
V. ACTIV 414 1200
— SYNC —
INT(G) NO NO
EXT(H/V)/POLARITY YES N/P YES P/P
EXT(CS) /POLARITY NO NO
INT/NON INT NON INT NON INT
TIMING SPECIFICATION
98.05.12 VER.
