Sony TRINITRON CPD-520GS - 7 Electrical Parts List

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-520GS/520GST/520GST9
7-1
NOTE:
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
(a2)
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
CPD-520GS/520GST/520GST9
* 8-933-334-00A2 BOARD, COMPLETE
*****************************
7-682-950-01 SCREW +PSW 3X12 (IC403)
<CAPACITOR>
C101 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C102 1-104-664-11 ELECT 47µF 20% 25V
C103 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C104 1-104-664-11 ELECT 47µF 20% 25V
C105 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C106 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C109 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C112 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C114 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C115 1-104-514-11 FILM 0.22µF 10% 250V
C120 1-107-949-11 ELECT 2.2µF 20% 200V
C124 1-163-016-00 CERAMIC CHIP 0.0039µF 10% 50V
C127 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C130 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C140 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C201 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C202 1-104-664-11 ELECT 47µF 20% 25V
C203 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C204 1-104-664-11 ELECT 47µF 20% 25V
C205 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C209 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C212 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C214 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C215 1-104-514-11 FILM 0.22µF 10% 250V
C217 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C220 1-107-949-11 ELECT 2.2µF 20% 200V
C222 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C224 1-163-016-00 CERAMIC CHIP 0.0039µF 10% 50V
C230 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C240 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C301 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C302 1-104-664-11 ELECT 47µF 20% 25V
C303 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C304 1-104-664-11 ELECT 47µF 20% 25V
C305 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C306 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C309 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C312 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C314 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C315 1-104-514-11 FILM 0.22µF 10% 250V
C317 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C320 1-107-949-11 ELECT 2.2µF 20% 200V
C324 1-163-016-00 CERAMIC CHIP 0.0039µF 10% 50V
C330 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C340 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C401 1-104-664-11 ELECT 47µF 20% 25V
C402 1-104-664-11 ELECT 47µF 20% 25V
C403 1-104-664-11 ELECT 47µF 20% 25V
C404 1-126-964-11 ELECT 10µF 20% 50V
C405 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C407 1-126-964-11 ELECT 10µF 20% 50V
C408 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C409 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C410 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C411 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C412 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C414 1-163-222-11 CERAMIC CHIP 5pF 0.25pF 50V
C415 1-128-562-11 ELECT 47µF 20% 100V
C416 1-104-664-11 ELECT 47µF 20% 25V
C417 1-115-349-51 CERAMIC 0.01µF 2KV
C419 1-162-318-11 CERAMIC 0.001µF 10% 500V
C420 1-126-967-11 ELECT 47µF 20% 50V
C421 1-126-964-11 ELECT 10µF 20% 50V
C424 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C425 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C429 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C431 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C434 1-162-318-11 CERAMIC 0.001µF 10% 500V
C435 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C436 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C438 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C440 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C442 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C443 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C444 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C445 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C446 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C447 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
