Sony TRINITRON CPD-520GS - Page 41

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-520GS/520GST/520GST9
7-2
(a2)
C448 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C450 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C451 1-104-664-11 ELECT 47µF 20% 25V
C452 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C453 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C454 1-104-665-11 ELECT 100µF 20% 25V
C455 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C457 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C460 1-162-318-11 CERAMIC 0.001µF 10% 500V
C461 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C463 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C464 1-107-906-11 ELECT 10µF 20% 50V
C465 1-107-906-11 ELECT 10µF 20% 50V
C466 1-126-964-11 ELECT 10µF 20% 50V
C467 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C468 1-126-964-11 ELECT 10µF 20% 50V
C469 1-126-964-11 ELECT 10µF 20% 50V
C470 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C471 1-162-318-11 CERAMIC 0.001µF 10% 500V
C478 1-115-350-51 CERAMIC 0.0047µF 2KV
C479 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C480 1-104-665-11 ELECT 100µF 20% 25V
C481 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C482 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C483 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C484 1-162-318-11 CERAMIC 0.001µF 10% 500V
C485 1-107-652-11 ELECT 10µF 20% 250V
C486 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C487 1-126-964-11 ELECT 10µF 20% 50V
C489 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C497 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
<CONNECTOR>
CN401*1-564-521-11 PLUG, CONNECTOR 6P
CN402*1-564-522-11 PLUG, CONNECTOR 7P
CN403*1-564-523-11 PLUG, CONNECTOR 8P
CN405*1-564-524-11 PLUG, CONNECTOR 9P
CN406*1-766-179-11 PIN, CONNECTOR (PC BOARD) 2P
CN407*1-564-522-11 PLUG, CONNECTOR 7P
<DIODE>
D101 8-719-062-51 DIODE 1PS226-115
D102 8-719-062-51 DIODE 1PS226-115
D103 8-719-404-50 DIODE MA111-TX
D104 8-719-052-12 DIODE 1SS376TE-17
D105 8-719-052-12 DIODE 1SS376TE-17
D106 8-719-052-12 DIODE 1SS376TE-17
D107 8-719-052-12 DIODE 1SS376TE-17
D201 8-719-062-51 DIODE 1PS226-115
D202 8-719-062-51 DIODE 1PS226-115
D203 8-719-404-50 DIODE MA111-TX
D204 8-719-052-12 DIODE 1SS376TE-17
D205 8-719-052-12 DIODE 1SS376TE-17
D206 8-719-052-12 DIODE 1SS376TE-17
D207 8-719-052-12 DIODE 1SS376TE-17
D301 8-719-062-51 DIODE 1PS226-115
D302 8-719-062-51 DIODE 1PS226-115
D303 8-719-404-50 DIODE MA111-TX
D304 8-719-052-12 DIODE 1SS376TE-17
D305 8-719-052-12 DIODE 1SS376TE-17
D306 8-719-052-12 DIODE 1SS376TE-17
D307 8-719-052-12 DIODE 1SS376TE-17
D401 8-719-404-50 DIODE MA111-TX
D404 8-719-052-12 DIODE 1SS376TE-17
D405 8-719-404-50 DIODE MA111-TX
D406 8-719-404-50 DIODE MA111-TX
D407 8-719-404-50 DIODE MA111-TX
D408 8-719-404-50 DIODE MA111-TX
D409 8-719-404-50 DIODE MA111-TX
D410 8-719-404-50 DIODE MA111-TX
<FERRITE BEAD>
FB101 1-216-295-91 SHORT 0
FB201 1-216-295-91 SHORT 0
FB301 1-216-295-91 SHORT 0
FB402 1-412-529-11 INDUCTOR 22µH
FB403 1-412-911-31 FERRITE 1.1µH
FB405 1-412-911-31 FERRITE 1.1µH
FB406 1-412-911-31 FERRITE 1.1µH
<IC>
IC401 8-759-522-86 IC M52755FP-TP
IC402 8-759-542-30 IC MM1383XD
IC403 8-749-013-90 IC VPS13
IC404 8-759-566-26 IC LSC4380DW2AR2
IC406 8-759-701-79 IC NJM7812FA
IC408 8-759-239-14 IC TA78L05S
IC409 8-759-502-82 IC LM324M
IC410 8-759-635-27 IC M62352GP-75E
IC413 8-759-082-57 IC TC7W04FU
<COIL>
L101 1-414-137-31 INDUCTOR 0.22µH
L102 1-414-137-31 INDUCTOR 0.22µH
L201 1-414-137-31 INDUCTOR 0.22µH
L202 1-414-137-31 INDUCTOR 0.22µH
L301 1-414-137-31 INDUCTOR 0.22µH
L302 1-414-137-31 INDUCTOR 0.22µH
L303 1-408-603-31 INDUCTOR 10µH
L401 1-408-615-31 INDUCTOR 100µH
L402 1-412-963-11 INDUCTOR 100µH
<IC LINK>
PS401!1-533-590-31LINK, IC (1A/90V AC, 60V DC)
