REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-3
<IC>
IC401 8-759-522-86 IC M52755FP-TP
IC402 8-759-468-63 IC M52722P
IC403 8-749-013-74 IC FA4111
IC404 8-759-566-26 IC LSC4380DW2AR2
IC406 8-759-701-79 IC NJM7812FA
IC408 8-759-239-14 IC TA78L05S
IC409 8-759-502-82 IC LM324M
IC410 8-759-635-27 IC M62352GP-75E
<CHIP CONDUCTOR>
JR401 1-216-295-91 SHORT 0 (A3 BOARD)
JR402 1-216-295-91 SHORT 0 (A3 BOARD)
JR403 1-216-295-91 SHORT 0 (A3 BOARD)
JR404 1-216-295-91 SHORT 0 (A3 BOARD)
<COIL>
L101 1-412-478-11 INDUCTOR 0.15µH
L201 1-412-478-11 INDUCTOR 0.15µH
L301 1-412-478-11 INDUCTOR 0.15µH
L401 1-408-615-31 INDUCTOR 100µH (A BOARD)
L401 1-414-940-21 INDUCTOR 100µH (A3 BOARD)
L402 1-412-529-11 INDUCTOR 22µH (A BOARD)
L402 1-414-742-21 INDUCTOR 22µH (A3 BOARD)
L403 1-412-963-11 INDUCTOR 100µH
<IC LINK>
PS401 ¡1-533-590-31LINK, IC (1A/90V AC, 60V DC)
<TRANSISTOR>
Q101 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q105 8-729-041-66 TRANSISTOR 2SC4015TV2
Q106 8-729-200-17 TRANSISTOR 2SA1091-O
Q201 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q202 8-729-107-31 TRANSISTOR 2SC3545-T43 (A BOARD)
Q202 8-729-402-07 TRANSISTOR 2SC2735JTL (A3 BOARD)
Q205 8-729-041-66 TRANSISTOR 2SC4015TV2
Q206 8-729-200-17 TRANSISTOR 2SA1091-O
Q301 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q305 8-729-041-66 TRANSISTOR 2SC4015TV2
Q306 8-729-200-17 TRANSISTOR 2SA1091-O
Q401 8-729-216-22 TRANSISTOR 2SA1162-G
Q402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q403 8-729-216-22 TRANSISTOR 2SA1162-G
Q404 8-729-901-00 TRANSISTOR DTC124EK
Q405 8-729-216-22 TRANSISTOR 2SA1162-G
Q406 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q408 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q409 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q410 8-729-032-61 TRANSISTOR 2SC5022-02
<RESISTOR>
R101 1-215-395-00 METAL 82 1% 1/4W
R102 1-216-025-91 RES, CHIP 100 5% 1/10W
R103 1-215-395-00 METAL 82 1% 1/4W
R104 1-216-025-91 RES, CHIP 100 5% 1/10W
R105 1-216-017-91 RES, CHIP 47 5% 1/10W
R106 1-216-017-91 RES, CHIP 47 5% 1/10W
R108 1-216-099-00 RES, CHIP 120K 5% 1/10W
R109 1-216-117-00 RES, CHIP 680K 5% 1/10W
R110 1-216-295-91 SHORT 0
R111 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R112 1-216-617-11 METAL CHIP 39 0.50%1/10W
(A BOARD)
R112 1-216-621-11 METAL CHIP 56 0.50%1/10W
(A3 BOARD)
R113 1-216-009-91 RES, CHIP 22 5% 1/10W
R114 1-216-035-00 RES, CHIP 270 5% 1/10W
R115 1-216-035-00 RES, CHIP 270 5% 1/10W
R116 1-216-017-91 RES, CHIP 47 5% 1/10W
R117 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R118 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R119 1-216-009-91 RES, CHIP 22 5% 1/10W
R120 1-216-097-91 RES, CHIP 100K 5% 1/10W
R121 1-216-097-91 RES, CHIP 100K 5% 1/10W
R122 1-216-027-00 RES, CHIP 120 5% 1/10W
R123 1-216-027-00 RES, CHIP 120 5% 1/10W
R124 1-219-497-11 CARBON 22 5% 1/2W
R125 1-216-091-00 RES, CHIP 56K 5% 1/10W
R126 1-216-097-91 RES, CHIP 100K 5% 1/10W
R127 1-216-035-00 RES, CHIP 270 5% 1/10W
R128 1-216-121-91 RES, CHIP 1M 5% 1/10W
R129 1-216-115-00 RES, CHIP 560K 5% 1/10W
(A3 BOARD)
R129 1-216-121-91 RES, CHIP 1M 5% 1/10W
(A BOARD)
R130 1-216-097-91 RES, CHIP 100K 5% 1/10W
R131 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R132 1-216-035-00 RES, CHIP 270 5% 1/10W
R133 1-216-049-91 RES, CHIP 1K 5% 1/10W
R134 1-216-097-91 RES, CHIP 100K 5% 1/10W
R135 1-216-037-00 RES, CHIP 330 5% 1/10W
R136 1-216-097-91 RES, CHIP 100K 5% 1/10W
R137 1-216-097-91 RES, CHIP 100K 5% 1/10W
R139 1-216-073-00 RES, CHIP 10K 5% 1/10W
R140 1-216-129-00 RES, CHIP 2.2M 5% 1/10W
(A BOARD)
R141 1-216-025-91 RES, CHIP 100 5% 1/10W
R144 1-216-295-91 SHORT 0
R145 1-216-113-00 RES, CHIP 470K 5% 1/10W
(A3 BOARD)
R167 1-216-121-91 RES, CHIP 1M 5% 1/10W
R201 1-215-395-00 METAL 82 1% 1/4W
R202 1-216-025-91 RES, CHIP 100 5% 1/10W
R203 1-215-395-00 METAL 82 1% 1/4W
R204 1-216-025-91 RES, CHIP 100 5% 1/10W
R205 1-216-017-91 RES, CHIP 47 5% 1/10W
R206 1-216-017-91 RES, CHIP 47 5% 1/10W
A or A3
