Sony TRINITRON GDM-500PS - Page 41

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-4
R208 1-216-099-00 RES, CHIP 120K 5% 1/10W
R209 1-216-117-00 RES, CHIP 680K 5% 1/10W
R210 1-216-295-91 SHORT 0
R211 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R212 1-216-621-11 METAL CHIP 56 0.50%1/10W
R213 1-216-009-91 RES, CHIP 22 5% 1/10W
R214 1-216-035-00 RES, CHIP 270 5% 1/10W
R215 1-216-035-00 RES, CHIP 270 5% 1/10W
R216 1-216-017-91 RES, CHIP 47 5% 1/10W
R217 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R218 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R219 1-216-009-91 RES, CHIP 22 5% 1/10W
R220 1-216-097-91 RES, CHIP 100K 5% 1/10W
R221 1-216-097-91 RES, CHIP 100K 5% 1/10W
R222 1-216-027-00 RES, CHIP 120 5% 1/10W
R223 1-216-027-00 RES, CHIP 120 5% 1/10W
R224 1-219-497-11 CARBON 22 5% 1/2W
R225 1-216-091-00 RES, CHIP 56K 5% 1/10W
R226 1-216-097-91 RES, CHIP 100K 5% 1/10W
R227 1-216-035-00 RES, CHIP 270 5% 1/10W
R228 1-216-121-91 RES, CHIP 1M 5% 1/10W
R229 1-216-115-00 RES, CHIP 560K 5% 1/10W
(A3 BOARD)
R229 1-218-121-91 RES, CHIP 1M 5% 1/10W
(A BOARD)
R230 1-216-097-91 RES, CHIP 100K 5% 1/10W
R231 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R232 1-216-035-00 RES, CHIP 270 5% 1/10W
R233 1-216-049-91 RES, CHIP 1K 5% 1/10W
R234 1-216-097-91 RES, CHIP 100K 5% 1/10W
R235 1-216-037-00 RES, CHIP 330 5% 1/10W
R236 1-216-097-91 RES, CHIP 100K 5% 1/10W
R237 1-216-097-91 RES, CHIP 100K 5% 1/10W
R239 1-216-073-00 RES, CHIP 10K 5% 1/10W
R240 1-216-129-00 RES, CHIP 2.2M 5% 1/10W
(A BOARD)
R241 1-216-025-91 RES, CHIP 100 5% 1/10W
R243 1-216-043-91 RES, CHIP 560 5% 1/10W
R244 1-216-295-91 SHORT 0
R245 1-216-113-00 RES, CHIP 470K 5% 1/10W
(A3 BOARD)
R267 1-216-121-91 RES, CHIP 1M 5% 1/10W
R301 1-215-395-00 METAL 82 1% 1/4W
R302 1-216-025-91 RES, CHIP 100 5% 1/10W
R303 1-215-395-00 METAL 82 1% 1/4W
R304 1-216-025-91 RES, CHIP 100 5% 1/10W
R305 1-216-017-91 RES, CHIP 47 5% 1/10W
R306 1-216-017-91 RES, CHIP 47 5% 1/10W
R308 1-216-099-00 RES, CHIP 120K 5% 1/10W
R309 1-216-117-00 RES, CHIP 680K 5% 1/10W
R310 1-216-295-91 SHORT 0
R311 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R312 1-216-619-11 METAL CHIP 47 0.50%1/10W
(A3 BOARD)
R312 1-216-623-11 METAL CHIP 68 0.50%1/10W
(A BOARD)
R313 1-216-009-91 RES, CHIP 22 5% 1/10W
R314 1-216-035-00 RES, CHIP 270 5% 1/10W
R315 1-216-035-00 RES, CHIP 270 5% 1/10W
R316 1-216-017-91 RES, CHIP 47 5% 1/10W
R317 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R318 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R319 1-216-009-91 RES, CHIP 22 5% 1/10W
R320 1-216-097-91 RES, CHIP 100K 5% 1/10W
R321 1-216-097-91 RES, CHIP 100K 5% 1/10W
R322 1-216-027-00 RES, CHIP 120 5% 1/10W
R323 1-216-027-00 RES, CHIP 120 5% 1/10W
R324 1-219-497-11 CARBON 22 5% 1/2W
R325 1-216-091-00 RES, CHIP 56K 5% 1/10W
R326 1-216-097-91 RES, CHIP 100K 5% 1/10W
R327 1-216-035-00 RES, CHIP 270 5% 1/10W
R328 1-216-121-91 RES, CHIP 1M 5% 1/10W
R329 1-216-115-00 RES, CHIP 560K 5% 1/10W
(A3 BOARD)
R329 1-216-121-91 RES, CHIP 1M 5% 1/10W
(A BOARD)
R330 1-216-097-91 RES, CHIP 100K 5% 1/10W
R331 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R332 1-216-035-00 RES, CHIP 270 5% 1/10W
R333 1-216-049-91 RES, CHIP 1K 5% 1/10W
R334 1-216-097-91 RES, CHIP 100K 5% 1/10W
R335 1-216-037-00 RES, CHIP 330 5% 1/10W
R336 1-216-097-91 RES, CHIP 100K 5% 1/10W
R337 1-216-097-91 RES, CHIP 100K 5% 1/10W
R339 1-216-073-00 RES, CHIP 10K 5% 1/10W
R340 1-216-129-00 RES, CHIP 2.2M 5% 1/10W
(A BOARD)
R341 1-216-025-91 RES, CHIP 100 5% 1/10W
R344 1-216-295-91 SHORT 0
R345 1-216-113-00 RES, CHIP 470K 5% 1/10W
(A3 BOARD)
R367 1-216-121-91 RES, CHIP 1M 5% 1/10W
R406 1-216-049-91 RES, CHIP 1K 5% 1/10W
R407 1-216-089-91 RES, CHIP 47K 5% 1/10W
R408 1-216-097-91 RES, CHIP 100K 5% 1/10W
R409 1-216-049-91 RES, CHIP 1K 5% 1/10W
R410 1-216-049-91 RES, CHIP 1K 5% 1/10W
R411 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R412 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R413 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R415 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R416 1-216-049-91 RES, CHIP 1K 5% 1/10W
R417 1-216-089-91 RES, CHIP 47K 5% 1/10W
R418 1-260-127-11 CARBON 220K 5% 1/2W
R419 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R420 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R421 1-216-103-00 RES, CHIP 180K 5% 1/10W
R422 1-216-025-91 RES, CHIP 100 5% 1/10W
R423 1-216-089-91 RES, CHIP 47K 5% 1/10W
R424 1-216-025-91 RES, CHIP 100 5% 1/10W
R425 1-216-017-91 RES, CHIP 47 5% 1/10W
R426 1-216-025-91 RES, CHIP 100 5% 1/10W
R427 1-216-025-91 RES, CHIP 100 5% 1/10W
A or A3
