REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-6
* 7-322-065-72 RUBBER, RTV (SE-9168) (130G)
(C671, C682, VDR640)
7-682-947-01 SCREW +PSW 3X6 (IC660)
<CAPACITOR>
C601¡ 1-113-900-51 CERAMIC 470pF 10% 250V
C602¡ 1-113-900-51 CERAMIC 470pF 10% 250V
C603¡ 1-107-533-51 FILM 1µF 20% 250V
C604¡ 1-107-533-51 FILM 1µF 20% 250V
C605¡ 1-113-926-91 CERAMIC 0.0047µF 250V
C606¡ 1-113-926-91 CERAMIC 0.0047µF 250V
C607 1-113-900-11 CERAMIC 470PF 10% 250V
C610 1-137-479-11 FILM 1µF 10% 400V
C611 1-117-849-11 ELECT 330µF 20% 450V
C612 1-126-959-11 ELECT 0.47µF 20% 50V
C616 1-107-888-11 ELECT 47µF 20% 25V
C640 1-104-330-91 CERAMIC 470pF 10% 1KV
C641 1-104-330-91 CERAMIC 470pF 10% 1KV
C642 1-136-171-00 FILM 0.33µF 5% 50V
C643 1-136-171-00 FILM 0.33µF 5% 50V
C644 1-104-330-91 CERAMIC 470pF 10% 1KV
C645 1-136-167-00 FILM 0.15µF 5% 50V
C646 1-136-167-00 FILM 0.15µF 5% 50V
C647 1-129-719-00 FILM 0.027µF 5% 630V
C660 1-111-057-11 ELECT 120µF 20% 25V
C661 1-128-526-11 ELECT 100µF 20% 16V
C662 1-130-495-00 FILM 0.1µF 5% 50V
C663 1-126-965-11 ELECT 22µF 20% 50V
C670 1-137-370-11 FILM 0.01µF 5% 50V
C671 1-107-966-51 ELECT 220µF 20% 250V
C672 1-107-959-11 ELECT 3.3µF 20% 250V
C673 1-107-935-11 ELECT 330µF 20% 100V
C674 1-107-928-11 ELECT 4.7µF 20% 100V
C675 1-107-890-11 ELECT 2200µF 20% 25V
C676 1-107-888-11 ELECT 47µF 20% 25V
C677 1-107-890-11 ELECT 2200µF 20% 25V
C678 1-107-888-11 ELECT 47µF 20% 25V
C679 1-126-927-11 ELECT 2200µF 20% 10V
C680 1-126-927-11 ELECT 2200µF 20% 10V
C681 1-107-905-11 ELECT 4.7µF 20% 50V
C682 1-126-963-11 ELECT 4.7µF 20% 50V
C683 1-164-646-11 CERAMIC 2200pF 10% 500V
C684 1-137-370-11 FILM 0.01µF 5% 50V
C685 1-107-909-11 ELECT 47µF 20% 50V
C690 1-107-888-11 ELECT 47µF 20% 25V
C691 1-107-888-11 ELECT 47µF 20% 25V
C692 1-111-016-11 ELECT 0.0012F 20% 10V
C693 1-130-495-00 FILM 0.1µF 5% 50V
C695 1-164-644-11 CERAMIC 330pF 10% 500V
C697 1-136-165-00 FILM 0.1µF 5% 50V
<CONNECTOR>
CN603*1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN604*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN605*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN610*1-774-511-11 CONNECTOR, BOARD TO BOARD 10P
CN671*1-764-334-11 PLUG, CONNECTOR 11P
CN672*1-564-512-11 PLUG, CONNECTOR 9P
CN673*1-564-508-11 PLUG, CONNECTOR 5P
<DIODE>
D610 ¡ 8-719-510-53 DIODE D4SB60L
D611 8-719-029-04 DIODE D5L60
D612 8-719-304-63 DIODE RM11C
D613 8-719-110-49 ZENER DIODE RD18ESB2
D614 8-719-977-28 ZENER DIODE DTZ10B
D617 8-719-404-50 DIODE MA111-TX
D640 8-719-404-50 DIODE MA111-TX
D660 8-719-059-23 DIODE P6KE200AG23
D661 8-719-979-64 DIODE UF4005PKG23
D662 8-719-058-91 DIODE AG01A-V0
D663 8-719-110-31 ZENER DIODE RD12ESB2
D666 8-719-105-99 ZENER DIODE RD6.2M-B1
D670 8-719-064-49 DIODE D4SBL40
D671 8-719-510-64 DIODE S2LA20F
D672 8-719-052-91 DIODE D4SBS4-F
D673 8-719-022-97 DIODE D2S4MF
D674 8-719-022-97 DIODE D2S4MF
D677 8-719-911-19 DIODE 1SS119-25
D678 8-719-911-19 DIODE 1SS119-25
D680 8-719-404-50 DIODE MA111
D681 8-719-404-50 DIODE MA111
D682 8-719-510-64 DIODE S2LA20F
D683 8-719-911-19 DIODE 1SS119-25
D684 8-719-110-57 ZENER DIODE RD22ESB2
D691 8-719-510-37 DIODE D5LC20U
D692 8-719-911-19 DIODE 1SS119-25
D693 8-719-404-50 DIODE MA111-TX
<FUSE>
F601 ¡ 1-576-233-11 FUSE (H.B.C.) (6.3A/250V)
<FERRITE BEAD>
FB610 1-410-396-41 FERRITE 0.45µH
FB611 1-410-396-41 FERRITE 0.45µH
FB612 1-410-396-41 FERRITE 0.45µH
<IC>
IC630 8-749-013-03 IC DM-60
IC660 8-759-470-64 IC TOP223Y-BB
IC690 8-749-011-42 IC SI-3050F
IC691 8-759-140-85 IC µPC1093J
<COIL>
L610 1-416-409-11 INDUCTOR 220µH
L611 1-411-674-11 INDUCTOR 68µH
(g)
