Sony TRINITRON GDM-500PS - Page 44

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-7
L670 1-412-529-11 INDUCTOR 22µH
L671 1-412-529-11 INDUCTOR 22µH
L672 1-412-529-11 INDUCTOR 22µH
L673 1-412-529-11 INDUCTOR 22µH
L691 1-412-529-11 INDUCTOR 22µH
<PHOTO COUPLER>
PH660 8-749-010-64 PHOTO COUPLER PC123F2
PH680 8-749-010-64 PHOTO COUPLER PC123F2
<IC LINK>
PS670¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
PS671¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
PS673¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
PS674¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
<TRANSISTOR>
Q610 8-729-041-65 TRANSISTOR 2SK2195F04
Q615 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q640 8-729-041-12 TRANSISTOR MX0841AB-F
Q641 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q642 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q660 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q680 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q681 8-729-230-45 TRANSISTOR 2SC2458-YGR
Q682 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q683 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q690 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q691 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
<RESISTOR>
R601 ¡ 1-220-825-91 CARBON 330K 5% 1/2W
R604 1-260-089-11 CARBON 150 5% 1/2W
R610 1-216-383-11 METAL OXIDE 0.33 5% 3W F
R611 1-216-383-11 METAL OXIDE 0.33 5% 3W F
R612 1-215-477-00 METAL 220K 1% 1/4W
R613 1-215-477-00 METAL 220K 1% 1/4W
R614 1-215-473-00 METAL 150K 1% 1/4W
R615 1-215-473-00 METAL 150K 1% 1/4W
R616 1-215-473-00 METAL 150K 1% 1/4W
R617 1-215-481-00 METAL 330K 1% 1/4W
R618 1-215-477-00 METAL 220K 1% 1/4W
R619 1-215-485-00 METAL 470K 1% 1/4W
R620 1-215-485-00 METAL 470K 1% 1/4W
R621 1-215-481-00 METAL 330K 1% 1/4W
R622 1-216-049-91 RES,CHIP 1K 5% 1/10W
R623 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R624 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R625 1-249-389-11 CARBON 4.7 5% 1/4W
R626 1-249-429-11 CARBON 10K 5% 1/4W
R627 1-215-479-00 METAL 270K 1% 1/4W
R628 1-215-481-00 METAL 330K 1% 1/4W
R629 1-215-461-00 METAL 47K 1% 1/4W
R631 1-247-807-31 CARBON 100 5% 1/4W
R632 1-216-073-00 RES, CHIP 10K 5% 1/10W
R633 1-215-481-00 METAL 330K 1% 1/4W
R635 1-216-073-00 RES, CHIP 10K 5% 1/10W
R640 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R641 1-218-642-11 METAL OXIDE 100K 5% 1W F
R642 1-218-642-11 METAL OXIDE 100K 5% 1W F
R643 1-247-863-91 CARBON 22K 5% 1/4W
R644 1-216-105-91 RES, CHIP 220K 5% 1/10W
R645 1-216-081-00 RES, CHIP 22K 5% 1/10W
R646 1-216-073-00 RES, CHIP 10K 5% 1/10W
R647 1-249-441-11 CARBON 100K 5% 1/4W
R648 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R649 1-218-642-11 METAL OXIDE 100K 5% 1W F
R650 1-218-642-11 METAL OXIDE 100K 5% 1W F
R651 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R652 1-212-942-00 FUSIBLE 2.2 5% 1/2W F
R655 1-216-073-00 RES, CHIP 10K 5% 1/10W
R661 1-249-387-11 CARBON 3.3 5% 1/4W F
R662 1-216-073-00 RES, CHIP 10K 5% 1/10W
R663 1-216-073-00 RES, CHIP 10K 5% 1/10W
R664 1-247-791-91 CARBON 22 5% 1/4W
R665 1-216-033-00 RES, CHIP 220 5% 1/10W
R666 1-215-441-00 METAL 6.8K 1% 1/4W
R667 1-215-433-00 METAL 3.3K 1% 1/4W
R668 1-249-401-11 CARBON 47 5% 1/4W
R669 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R671 1-216-113-00 RES, CHIP 470K 5% 1/10W
R672 1-216-049-91 RES, CHIP 1K 5% 1/10W
R673 1-249-413-11 CARBON 470 5% 1/4W F
R674 1-249-377-11 CARBON 0.47 5% 1/4W F
R675 1-260-292-11 CARBON 1 5% 1/2W
R676 1-249-413-11 CARBON 470 5% 1/4W
R680 1-216-073-00 RES, CHIP 10K 5% 1/10W
R681 1-216-049-91 RES, CHIP 1K 5% 1/10W
R682 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R683 1-216-025-91 RES, CHIP 100 5% 1/10W
R685 1-216-073-00 RES, CHIP 10K 5% 1/10W
R686 1-216-049-91 RES, CHIP 1K 5% 1/10W
R687 1-216-049-91 RES, CHIP 1K 5% 1/10W
R688 1-216-073-00 RES, CHIP 10K 5% 1/10W
R689 1-216-073-00 RES, CHIP 10K 5% 1/10W
R691 1-216-073-00 RES, CHIP 10K 5% 1/10W
R692 1-260-085-11 CARBON 68 5% 1/2W
R693 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R694 1-216-073-00 RES, CHIP 10K 5% 1/10W
R695 1-249-443-11 CARBON 0.47 5% 1/4W F
R696 1-216-633-11 METAL CHIP 180 0.50%1/10W
R697 1-216-649-11 METAL CHIP 820 0.50%1/10W
R698 1-216-073-00 RES, CHIP 10K 5% 1/10W
R699 1-216-081-00 RES, CHIP 22K 5% 1/10W
<RELAY>
RY601¡1-515-669-21RELAY
(g)
