Sony TRINITRON GDM-500PS - Page 45

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-8
RY602¡1-755-031-11RELAY
<TRANSFORMER>
T601¡ 1-429-180-11 TRANSFORMER, LINE FILTER
T640 1-431-538-11 TRANSFORMER, CONVERTER (PIT)
T641 1-429-992-11 TRANSFORMER, CONVERTER (PRT)
T660 1-431-565-11 TRANSFORMER, CONVERTER (SRT)
<THERMISTOR>
TH601 ¡1-809-260-11THERMISTOR, POWER
THP601¡1-809-827-11THERMISTOR, POSITIVE
<VARISTOR>
VDR601 ¡1-801-268-51VARISTOR TNR14V471K660
VDR602 ¡1-810-622-21VARISTOR
VDR640 1-810-974-21VARISTOR TNR10V431K660
*******************************************************************************
* 8-933-276-00 D BOARD, COMPLETE
****************************
4-040-989-01 SPRING (A), TR RETAINER (IC702)
4-040-992-01 SPRING (AA), TR RETAINER
(IC502, Q507)
4-040-994-01 SPRING (BB), TR RETAINER
(Q508, D519)
4-047-285-01 SHEET, INSULATING (Q909)
4-060-719-02 SHEET, INSULATE (IC502)
4-060-720-01 SHEET, INSULATE (Q508)
4-060-844-01 SHEET, INSULATING (IC702)
4-382-854-01 SCREW (M3X8), P, SW (+) (R937)
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC702, Q704, Q706, Q908, Q909)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
(IC502, Q507, Q508, D519, R511)
<CAPACITOR>
C001 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C002 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C003 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C005 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C007 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C008 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C009 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C010 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C011 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C012 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C013 1-126-967-11 ELECT 47µF 20% 50V
C014 1-107-914-11 ELECT 1000µF 20% 25V
C015 1-107-914-11 ELECT 1000µF 20% 25V
C016 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C017 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C018 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C019 1-126-967-11 ELECT 47µF 20% 50V
C020 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C021 1-163-023-00 CERAMIC CHIP 0.015µF 10% 50V
C022 1-126-933-11 ELECT 100µF 20% 16V
C023 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C025 1-126-960-11 ELECT 1µF 20% 50V
C026 1-137-372-11 FILM 0.022µF 5% 50V
C027 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C028 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C029 1-126-960-11 ELECT 1µF 20% 50V
C030 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C031 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C032 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C034 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C035 1-163-253-11 CERAMIC CHIP 120pF 5% 50V
C036 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C037 1-126-934-11 ELECT 220µF 20% 16V
C038 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C039 1-126-964-11 ELECT 10µF 20% 50V
C040 1-126-963-11 ELECT 4.7µF 20% 50V
C041 1-126-960-11 ELECT 1µF 20% 50V
C042 1-126-967-11 ELECT 47µF 20% 50V
C043 1-126-967-11 ELECT 47µF 20% 50V
C044 1-126-967-11 ELECT 47µF 20% 50V
C045 1-163-137-00 CERAMIC CHIP 680pF 5% 50V
C046 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C047 1-126-934-11 ELECT 220µF 20% 16V
C048 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C049 1-163-137-00 CERAMIC CHIP 680pF 5% 50V
C050 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C051 1-126-960-11 ELECT 1µF 20% 50V
C052 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C054 1-126-963-11 ELECT 4.7µF 20% 50V
C055 1-126-963-11 ELECT 4.7µF 20% 50V
C056 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C057 1-107-909-11 ELECT 47µF 20% 50V
C058 1-126-934-11 ELECT 220µF 20% 16V
C059 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C060 1-126-964-11 ELECT 10µF 20% 50V
C061 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C063 1-130-495-00 FILM 0.1µF 5% 50V
C065 1-126-965-11 ELECT 22µF 20% 50V
C066 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C067 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C068 1-126-964-11 ELECT 10µF 20% 50V
C069 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C070 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C072 1-126-960-11 ELECT 1µF 20% 50V
C073 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C074 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C075 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C076 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C077 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C078 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
