Sony TRINITRON GDM-500PS - Page 48

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-11
D921 8-719-404-50 DIODE MA111-TX
D922 8-719-404-50 DIODE MA111-TX
D923 8-719-404-50 DIODE MA111-TX
D924 8-719-976-99 ZENER DIODE DTZ5.1B
D935 8-719-977-81 ZENER DIODE DTZ33B
D1501 8-719-976-99 ZENER DIODE DTZ5.1B
D1502 8-719-404-50 DIODE MA111-TX
D1503 8-719-404-50 DIODE MA111-TX
<FERRITE BEAD>
FB501 1-410-397-21 INDUCTOR, FERRITE BEAD 1.1µH
FB502 1-410-397-21 INDUCTOR, FERRITE BEAD 1.1µH
FB901 1-410-397-21 INDUCTOR, FERRITE BEAD 1.1µH
FB10251-414-232-11 INDUCTOR, FERRITE BEAD 1.1µH
<IC>
IC001 8-759-531-24 IC MB90553PF-G-120-BND
IC002 8-759-442-20 IC 24LC21AT/SN
IC003 8-759-168-20 IC TA78L09S
IC004 8-759-454-79 IC 24LC16BT/SN
IC005 8-759-162-80 IC MM1170BFB
IC006 8-759-231-53 IC TA7805S
IC007 8-752-078-46 IC CXA2043Q
IC008 8-759-701-59 IC NJM78M09FA
IC009 8-759-082-57 IC TC7W04FU
IC010 8-752-083-83 IC CXA2044M-T6
IC011 8-759-708-05 IC NJM78L05A
IC013 8-759-233-66 IC TC74HCT04AF
IC502 8-759-803-42 IC LA6500-FA
IC505 8-759-100-96 IC µPC4558G2
IC701 8-759-822-38 IC LA6510
IC702 8-759-444-82 IC LA7841L
IC703 8-759-100-96 IC µPC4558G2
IC901 8-759-467-70 IC BA9756FS-E2
<CHIP CONDUCTOR>
JR001 1-216-295-91 SHORT 0
JR002 1-216-295-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR004 1-216-295-91 SHORT 0
<COIL>
L001 1-406-665-11 COIL, CHOKE 100µH
L002 1-406-665-11 COIL, CHOKE 100µH
L003 1-412-537-31 INDUCTOR 100µH
L004 1-412-537-31 INDUCTOR 100µH
L006 1-410-482-31 INDUCTOR 100µH
L007 1-412-537-31 INDUCTOR 100µH
L008 1-412-537-31 INDUCTOR 100µH
L501 1-412-537-31 INDUCTOR 100µH
L502 1-406-671-11 COIL, CHOKE 1.0mH
L503 1-416-455-11 COIL, HORIZONTAL LINEARITY
L504 1-416-456-11 COIL, HORIZONTAL LINEARITY
L505 1-406-675-11 COIL, CHOKE 4.7mH
L507 1-406-675-11 COIL, CHOKE 4.7mH
L701 1-412-537-31 INDUCTOR 100µH
L702 1-412-522-31 INDUCTOR 5.6µH
L901 1-412-537-31 INDUCTOR 100µH
L902 1-406-660-41 COIL, CHOKE 15µH
L903 1-412-537-31 INDUCTOR 100µH
<IC LINK>
PS501¡ 1-533-592-31 LINK, IC (1.6A/90V AC, 60V DC)
PS502¡ 1-532-984-91 LINK, IC (2A/90V)
PS503¡ 1-532-984-91 LINK, IC (2A/90V)
PS504¡ 1-532-984-91 LINK, IC (2A/90V)
PS701¡ 1-533-590-31 LINK, IC (1A/90V AC, 60V DC)
PS901¡ 1-533-592-31 LINK, IC (1.6A/90V AC, 60V DC)
<TRANSISTOR>
Q001 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q003 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q004 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q005 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q007 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q503 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q504 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q505 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q506 8-729-820-73 TRANSISTOR 2SC3746
Q507 8-729-035-54 TRANSISTOR 2SJ449
Q508 8-729-031-87 TRANSISTOR 2SC5047-CA
Q509 8-729-033-25 TRANSISTOR DTC114GKA
Q510 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q511 8-729-140-50 TRANSISTOR 2SC3209LK
Q512 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q517 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q522 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q523 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q524 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q525 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q526 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q527 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q528 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q660 8-729-033-26 TRANSISTOR DTA114GKAT146
Q661 8-729-033-25 TRANSISTOR DTC114GKA
Q701 8-729-800-32 TRANSISTOR 2SC2362K-G
Q703 8-729-178-43 TRANSISTOR 2SC2784-E
Q704 8-729-207-82 TRANSISTOR 2SC3421-Y
Q705 8-729-204-91 TRANSISTOR 2SA1049-GR
Q706 8-729-207-89 TRANSISTOR 2SA1358-Y
Q707 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q708 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
Q901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q902 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
(d)
