Sony TRINITRON GDM-500PS - Page 49

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-12
Q904 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q905 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q908 8-729-035-54 TRANSISTOR 2SJ449
Q909 8-729-033-91 TRANSISTOR 2SK1120LBSONY2
Q911 8-729-033-25 TRANSISTOR DTC114GKA
<RESISTOR>
R001 1-216-025-91 RES, CHIP 100 5% 1/10W
R002 1-216-049-91 RES, CHIP 1K 5% 1/10W
R003 1-216-049-91 RES, CHIP 1K 5% 1/10W
R004 1-216-049-91 RES, CHIP 1K 5% 1/10W
R005 1-216-073-00 RES, CHIP 10K 5% 1/10W
R006 1-216-049-91 RES, CHIP 1K 5% 1/10W
R007 1-216-025-91 RES, CHIP 100 5% 1/10W
R008 1-216-089-91 RES, CHIP 47K 5% 1/10W
R009 1-216-025-91 RES, CHIP 100 5% 1/10W
R010 1-216-081-00 RES, CHIP 22K 5% 1/10W
R011 1-216-097-91 RES, CHIP 100K 5% 1/10W
R012 1-216-025-91 RES, CHIP 100 5% 1/10W
R013 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R017 1-216-049-91 RES, CHIP 1K 5% 1/10W
R018 1-216-049-91 RES, CHIP 1K 5% 1/10W
R020 1-216-049-91 RES, CHIP 1K 5% 1/10W
R023 1-216-025-91 RES, CHIP 100 5% 1/10W
R024 1-216-089-91 RES, CHIP 47K 5% 1/10W
R025 1-216-295-91 SHORT 0
R026 1-216-073-00 RES, CHIP 10K 5% 1/10W
R027 1-216-073-00 RES, CHIP 10K 5% 1/10W
R030 1-216-017-91 RES, CHIP 47 5% 1/10W
R031 1-216-073-00 RES, CHIP 10K 5% 1/10W
R032 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R033 1-216-017-91 RES, CHIP 47 5% 1/10W
R034 1-216-025-91 RES, CHIP 100 5% 1/10W
R035 1-216-049-91 RES, CHIP 1K 5% 1/10W
R036 1-216-025-91 RES, CHIP 100 5% 1/10W
R037 1-216-686-11 METAL CHIP 30K 0.50%1/10W
R038 1-216-685-11 METAL CHIP 27K 0.50%1/10W
R039 1-216-049-91 RES, CHIP 1K 5% 1/10W
R040 1-216-049-91 RES, CHIP 1K 5% 1/10W
R041 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R042 1-216-089-91 RES, CHIP 47K 5% 1/10W
R043 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R044 1-216-095-00 RES, CHIP 82K 5% 1/10W
R045 1-216-073-00 RES, CHIP 10K 5% 1/10W
R046 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R047 1-216-073-00 RES, CHIP 10K 5% 1/10W
R048 1-216-049-91 RES, CHIP 1K 5% 1/10W
R050 1-216-025-91 RES, CHIP 100 5% 1/10W
R051 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R052 1-216-073-00 RES, CHIP 10K 5% 1/10W
R053 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R054 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R055 1-216-089-91 RES, CHIP 47K 5% 1/10W
R056 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R057 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R058 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R059 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R060 1-216-025-91 RES, CHIP 100 5% 1/10W
R061 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R063 1-216-025-91 RES, CHIP 100 5% 1/10W
R064 1-216-025-91 RES, CHIP 100 5% 1/10W
R065 1-216-025-91 RES, CHIP 100 5% 1/10W
R066 1-216-025-91 RES, CHIP 100 5% 1/10W
R067 1-216-025-91 RES, CHIP 100 5% 1/10W
R068 1-216-025-91 RES, CHIP 100 5% 1/10W
R069 1-216-017-91 RES, CHIP 47 5% 1/10W
R070 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R071 1-216-049-91 RES, CHIP 1K 5% 1/10W
R072 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R073 1-216-295-91 SHORT 0
R074 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R075 1-216-049-91 RES, CHIP 1K 5% 1/10W
R076 1-216-049-91 RES, CHIP 1K 5% 1/10W
R077 1-216-049-91 RES, CHIP 1K 5% 1/10W
R078 1-216-049-91 RES, CHIP 1K 5% 1/10W
R081 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R082 1-216-049-91 RES, CHIP 1K 5% 1/10W
R083 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R084 1-216-025-91 RES, CHIP 100 5% 1/10W
R085 1-216-025-91 RES, CHIP 100 5% 1/10W
R086 1-216-049-91 RES, CHIP 1K 5% 1/10W
R088 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R089 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R090 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R092 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R094 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R096 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R097 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R101 1-216-049-91 RES, CHIP 1K 5% 1/10W
R501 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R502 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R503 1-216-041-00 RES, CHIP 470 5% 1/10W
R504 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R505 1-216-041-00 RES, CHIP 470 5% 1/10W
R506 1-249-397-11 CARBON 22 5% 1/4W F
R507 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R508 1-216-025-91 RES, CHIP 100 5% 1/10W
R509 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R510 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R511 1-219-726-11 METAL 2.2 5% 10W
R512 1-216-627-11 METAL CHIP 100 0.50%1/10W
R513 1-215-860-11 METAL OXIDE 33 5% 1W F
R514 1-211-796-11 FUSIBLE 1 5% 1/2W F
R515 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R516 1-247-815-91 CARBON 220 5% 1/4W
R517 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R518 1-216-097-91 RES, CHIP 100K 5% 1/10W
R519 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R520 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R521 1-249-413-11 CARBON 470 5% 1/4W F
R522 1-216-423-11 METAL OXIDE 27 5% 1W F
(d)
