REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-13
R523 1-249-421-11 CARBON 2.2K 5% 1/4W F
R524 1-215-869-11 METAL OXIDE 1K 5% 1W F
R525 1-216-681-11 METAL CHIP 18K 0.50%1/10W
R526 1-214-840-00 METAL 100 1% 1/2W
R527 1-214-840-00 METAL 100 1% 1/2W
R528 1-214-840-00 METAL 100 1% 1/2W
R529 1-260-313-51 CARBON 56 5% 1/2W
R530 1-249-437-11 CARBON 47K 5% 1/4W
R531 1-249-437-11 CARBON 47K 5% 1/4W
R532 1-249-437-11 CARBON 47K 5% 1/4W
R533 1-249-437-11 CARBON 47K 5% 1/4W
R534 1-249-437-11 CARBON 47K 5% 1/4W
R535 1-216-049-91 RES, CHIP 1K 5% 1/10W
R536 1-216-049-91 RES, CHIP 1K 5% 1/10W
R537 1-216-049-91 RES, CHIP 1K 5% 1/10W
R538 1-216-049-91 RES, CHIP 1K 5% 1/10W
R539 1-216-049-91 RES, CHIP 1K 5% 1/10W
R540 1-216-073-00 RES, CHIP 10K 5% 1/10W
R541 1-260-314-11 CARBON 68 5% 1/2W
R542 1-215-863-11 METAL OXIDE 100 5% 1W F
R543 1-216-640-11 METAL CHIP 360 0.50%1/10W
R544 1-260-085-11 CARBON 68 5% 1/2W
R545 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R546 1-260-288-11 CARBON 0.47 5% 1/2W
R547 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R548 1-215-443-00 METAL 8.2K 1% 1/4W
R549 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R550 1-260-288-11 CARBON 0.47 5% 1/2W
R551 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R552 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R553 1-216-655-11 METAL CHIP 1.5K 0.50%1/10W
R554 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R555 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R556 1-216-674-11 METAL CHIP 9.1K 0.50%1/10W
R557 1-218-760-11 METAL CHIP 220K 0.50%1/10W
R558 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R561 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R562 1-249-401-11 CARBON 47 5% 1/4W F
R563 1-216-662-11 METAL CHIP 3K 0.50%1/10W
R564 1-216-697-91 METAL CHIP 82K 0.50%1/10W
R565 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R566 1-260-311-11 CARBON 39 5% 1/2W
R567 1-216-627-11 METAL CHIP 100 0.50%1/10W
R568 1-216-655-11 METAL CHIP 1.5K 0.50%1/10W
R571 1-216-381-11 METAL OXIDE 0.22 5% 3W F
R572 1-216-097-91 RES, CHIP 100K 5% 1/10W
R573 1-216-097-91 RES, CHIP 100K 5% 1/10W
R574 1-216-097-91 RES, CHIP 100K 5% 1/10W
R575 1-216-097-91 RES, CHIP 100K 5% 1/10W
R576 1-216-097-91 RES, CHIP 100K 5% 1/10W
R577 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R578 1-216-025-91 RES, CHIP 100 5% 1/10W
R579 1-216-672-11 METAL CHIP 7.5K 0.50%1/10W
R580 1-216-073-00 RES, CHIP 10K 5% 1/10W
R581 1-216-073-00 RES, CHIP 10K 5% 1/10W
R582 1-216-073-00 RES, CHIP 10K 5% 1/10W
R583 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R584 1-216-081-00 RES, CHIP 22K 5% 1/10W
R585 1-216-081-00 RES, CHIP 22K 5% 1/10W
R586 1-216-049-91 RES, CHIP 1K 5% 1/10W
R587 1-216-049-91 RES, CHIP 1K 5% 1/10W
R588 1-216-097-91 RES, CHIP 100K 5% 1/10W
R589 1-216-097-91 RES, CHIP 100K 5% 1/10W
R590 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R591 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R594 1-249-437-11 CARBON 47K 5% 1/4W
R595 1-249-437-11 CARBON 47K 5% 1/4W
R596 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R663 1-215-482-00 METAL 360K 1% 1/4W
R664 1-215-459-00 METAL 39K 1% 1/4W
R665 1-216-049-91 RES, CHIP 1K 5% 1/10W
R667 1-216-041-00 RES, CHIP 470 5% 1/10W
R669 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R701 1-249-383-11 CARBON 1.5 5% 1/4W F
R702 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R703 1-216-085-00 RES, CHIP 33K 5% 1/10W
R704 1-249-383-11 CARBON 1.5 5% 1/4W F
R705 1-249-385-11 CARBON 2.2 5% 1/4W
R706 1-216-093-91 RES, CHIP 68K 5% 1/10W
R707 1-249-421-11 CARBON 2.2K 5% 1/4W
R708 1-216-073-00 RES, CHIP 10K 5% 1/10W
R709 1-216-473-11 METAL OXIDE 56 5% 3W F
R710 1-216-073-00 RES, CHIP 10K 5% 1/10W
R715 1-216-077-00 RES, CHIP 15K 5% 1/10W
R719 1-249-383-11 CARBON 1.5 5% 1/4W F
R720 1-260-292-11 CARBON 1 5% 1/2W
R721 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R722 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R723 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R724 1-214-798-21 METAL 1.8 1% 1/2W
R725 1-214-798-21 METAL 1.8 1% 1/2W
R726 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R727 1-260-292-11 CARBON 1 5% 1/2W
R728 1-249-381-11 CARBON 1 5% 1/4W F
R729 1-215-865-11 METAL OXIDE 220 5% 1W F
R730 1-219-746-11 CARBON 1K 5% 1/2W
R731 1-216-073-00 RES, CHIP 10K 5% 1/10W
R732 1-216-073-00 RES, CHIP 10K 5% 1/10W
R733 1-219-746-11 CARBON 1K 5% 1/2W
R734 1-215-881-11 METAL OXIDE 15 5% 2W F
R737 1-249-377-11 CARBON 0.47 5% 1/4W F
R738 1-249-377-11 CARBON 0.47 5% 1/4W F
R739 1-249-413-11 CARBON 470 5% 1/4W F
R741 1-249-430-11 CARBON 12K 5% 1/4W
R742 1-249-419-11 CARBON 1.5K 5% 1/4W
R743 1-216-049-91 RES,CHIP 1K 5% 1/10W
R748 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R749 1-216-049-91 RES, CHIP 1K 5% 1/10W
R750 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R751 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R752 1-216-083-00 RES, CHIP 27K 5% 1/10W
