Sony TRINITRON GDM-500PS - Page 51

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-14
R753 1-219-720-11 METAL 10M 5% 1W
R754 1-219-754-11 CARBON 680K 5% 1/2W
R755 1-219-754-11 CARBON 680K 5% 1/2W
R756 1-220-824-11 CARBON 270K 5% 1/2W
R759 1-218-754-11 METAL CHIP 120K 0.50%1/10W
R776 1-216-049-91 RES, CHIP 1K 5% 1/10W
R777 1-216-681-11 METAL CHIP 18K 0.50%1/10W
R778 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R779 1-216-049-91 RES, CHIP 1K 5% 1/10W
R784 1-216-081-00 RES, CHIP 22K 5% 1/10W
R900 1-216-399-00 METAL OXIDE 6.8 5% 3W F
R901 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R902 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R903 1-216-073-00 RES, CHIP 10K 5% 1/10W
R904 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R905 1-216-025-91 RES, CHIP 100 5% 1/10W
R906 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R907 1-216-025-91 RES, CHIP 100 5% 1/10W
R908 1-216-091-00 RES, CHIP 56K 5% 1/10W
R909 1-216-689-11 RES, CHIP 39K 5% 1/10W
R910 1-216-073-00 RES, CHIP 10K 5% 1/10W
R911 1-216-049-91 RES, CHIP 1K 5% 1/10W
R912 1-218-768-11 METAL CHIP 470K 0.50%1/10W
R913 1-219-748-11 CARBON 4.7K 5% 1/2W
R914 1-219-510-11 CARBON 470K 5% 1/2W
R915 1-249-437-11 CARBON 47K 5% 1/4W
R916 1-249-429-11 CARBON 10K 5% 1/4W
R917 1-216-073-00 RES, CHIP 10K 5% 1/10W
R918 1-216-097-91 RES, CHIP 100K 5% 1/10W
R919 1-216-025-91 RES, CHIP 100 5% 1/10W
R920 1-249-401-11 CARBON 47 5% 1/4W F
R921 1-216-668-11 METAL CHIP 5.1K 0.50%1/10W
R922 1-216-041-00 RES, CHIP 470 5% 1/10W
R923 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R924 1-249-397-11 CARBON 22 5% 1/4W F
R925 1-216-653-11 METAL CHIP 1.2K 0.50%1/10W
R926 1-216-653-11 METAL CHIP 1.2K 0.50%1/10W
R927 1-216-073-00 RES, CHIP 10K 5% 1/10W
R928 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R929 1-216-033-00 RES, CHIP 220 5% 1/10W
R930 1-216-033-00 RES, CHIP 220 5% 1/10W
R933 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R934 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R937 1-219-727-11 METAL 68 5% 10W
R940 1-249-393-11 CARBON 10 5% 1/4W F
R941 1-216-073-00 RES, CHIP 10K 5% 1/10W
R980 1-216-049-91 RES, CHIP 1K 5% 1/10W
R981 1-216-025-91 RES, CHIP 100 5% 1/10W
R1001 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1003 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1004 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1005 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1006 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1007 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1009 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1011 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1012 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1013 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1014 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1015 1-216-295-91 SHORT 0
R1016 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1017 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1020 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1021 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1022 1-216-295-91 SHORT 0
R1023 1-216-295-91 SHORT 0
R1024 1-216-295-91 SHORT 0
R1025 1-249-389-11 CARBON 4.7 5% 1/4W F
R1027 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1028 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1501 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1502 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1503 1-216-125-00 RES, CHIP 1.5M 5% 1/10W
R1504 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1513 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1514 1-216-049-91 RES, CHIP 1K 5% 1/10W
<RELAY>
RY501 1-755-137-11 RELAY
<SPARK GAP>
SG701 1-519-422-11 GAP, SPARK
SG702 1-519-422-11 GAP, SPARK
SG901 1-517-499-21 GAP, SPARK
<TRANSFORMER>
T501 1-429-303-21 TRANSFORMER, FERRITE (HDT)
T502 1-416-401-11 COIL, CHOKE 5mH
T503 1-431-413-11 TRANSFORMER, FERRITE (HST)
T504 1-416-257-11 COIL, CHOKE (HCC) 2.0MH
T701 1-431-414-11 TRANSFORMER, FERRITE (DFT)
T901 1-416-402-11 COIL, CHOKE 500µH
T902¡ X-4035-170-1 TRANSFORMER ASSY, FLYBACK
(NX-4142//J1D4)
<THERMISTOR>
TH501 1-807-796-11 THERMISTOR
TH502 1-807-796-11 THERMISTOR
<CRYSTAL>
X001 1-567-781-61 VIBRATOR, CRYSTAL (4MHz)
********************************************************************************
