REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-15
* 8-933-278-00 H BOARD, COMPLETE
****************************
<CAPACITOR>
C805 1-113-340-11 ELECT 47µF 20% 25V
C811 1-113-340-11 ELECT 47µF 20% 25V
<CONNECTOR>
CN801*1-564-526-11 PLUG, CONNECTOR 11P
<DIODE>
D810 8-719-064-11 DIODE SPR-325MVW
D812 8-719-060-26 DIODE SLR-325YCT31
D813 8-719-060-26 DIODE SLR-325YCT31
<TRANSISTOR>
Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q803 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q804 8-729-119-78 TRANSISTOR 2SC2785-HFE
<RESISTOR>
R801 1-215-433-00 METAL 3.3K 1% 1/4W
R802 1-215-409-00 METAL 330 1% 1/4W
R803 1-215-409-00 METAL 330 1% 1/4W
R804 1-215-413-00 METAL 470 1% 1/4W
R805 1-215-413-00 METAL 470 1% 1/4W
R806 1-215-417-00 METAL 680 1% 1/4W
R807 1-215-421-00 METAL 1K 1% 1/4W
R808 1-215-421-00 METAL 1K 1% 1/4W
R809 1-215-429-00 METAL 2.2K 1% 1/4W
R810 1-215-433-00 METAL 3.3K 1% 1/4W
R812 1-247-815-91 CARBON 220 5% 1/4W
R813 1-247-815-91 CARBON 220 5% 1/4W
R814 1-249-429-11 CARBON 10K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R816 1-247-863-91 CARBON 22K 5% 1/4W
R817 1-247-863-91 CARBON 22K 5% 1/4W
R818 1-215-445-00 METAL 10K 1% 1/4W
R819 1-249-441-11 CARBON 100K 5% 1/4W
R824 1-247-863-91 CARBON 22K 5% 1/4W
R825 1-247-863-91 CARBON 22K 5% 1/4W
R826 1-249-408-11 CARBON 180 5% 1/4W
R827 1-249-407-11 CARBON 150 5% 1/4W
<SWITCH>
S802 1-692-431-21 SWITCH, TACTILE (CONT+)
S803 1-692-431-21 SWITCH, TACTILE (CONT-)
S804 1-692-431-21 SWITCH, TACTILE (MENU)
S805 1-692-431-21 SWITCH, TACTILE (BRT+)
S806 1-692-431-21 SWITCH, TACTILE (BRT-)
S807 1-692-431-21 SWITCH, TACTILE (INPUT)
S808 1-692-431-21 SWITCH, TACTILE (ASC)
S810 1-692-431-21 SWITCH, TACTILE (RESET)
<THERMISTOR>
TH801 1-807-796-11 THERMISTOR
*******************************************************************************
* 8-933-279-00 J BOARD, COMPLETE
****************************
<CONNECTOR>
CN891*1-691-961-11 PIN, CONNECTOR (PC BOARD) 2P
<SWITCH>
S891 ¡ 1-571-433-31 SWITCH, PUSH (AC POWER)
*******************************************************************************
* 8-933-263-00 L BOARD, COMPLETE
* A-1394-929-A L3 BOARD, COMPLETE
*****************************
Note: L complete board and L3 complete board
have interchangeability though it is a little
different because the material of the circuit
board is different.
<CAPACITOR>
C5002 1-126-964-11 ELECT 10µF 20% 50V
C5003 1-126-933-11 ELECT 100µF 20% 16V
C5004 1-104-664-11 ELECT 47µF 20% 25V
C5005 1-104-664-11 ELECT 47µF 20% 25V
C5008 1-104-664-11 ELECT 47µF 20% 25V
C5009 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5101 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5103 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5105 1-104-664-11 ELECT 47µF 20% 25V
C5106 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5107 1-130-495-00 FILM 0.1µF 5% 50V
C5108 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5109 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5110 1-104-664-11 ELECT 47µF 20% 25V
C5111 1-130-495-00 FILM 0.1µF 5% 50V
C5201 1-104-664-11 ELECT 47µF 20% 25V
C5202 1-104-664-11 ELECT 47µF 20% 25V
C5203 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5204 1-130-495-00 FILM 0.1µF 5% 50V
(h)(j)
L or L3
To Next Page
