99
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< CAPACITOR >
C2301 1-126-934-11 ELECT 220MF 20% 16V
C2302 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2303 1-126-964-11 ELECT 10MF 20% 50V
C2304 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C2305 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C2306 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C2307 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2308 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C2309 1-126-934-11 ELECT 220MF 20% 16V
C2311 1-126-963-11 ELECT 4.7MF 20% 50V
C2312 1-126-963-11 ELECT 4.7MF 20% 50V
C2313 1-126-963-11 ELECT 4.7MF 20% 50V
C2314 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C2315 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C2316 1-110-501-11 CERAMIC CHIP 0.33MF 10% 16V
C2317 1-162-638-11 CERAMIC CHIP 1MF 16V
C2318 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C2319 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C2320 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C2323 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C2324 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2325 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2327 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2328 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2329 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2330 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2331 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2332 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C2333 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2334 1-126-964-11 ELECT 10MF 20% 50V
C2335 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2337 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C2338 1-126-934-11 ELECT 220MF 20% 16V
C2339 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C2340 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2342 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2343 1-126-961-11 ELECT 2.2MF 20% 50V
C2344 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2345 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2346 1-126-964-11 ELECT 10MF 20% 50V
C2347 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C2348 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C2349 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2350 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2351 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2354 1-126-934-11 ELECT 220MF 20% 16V
C2356 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2357 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2358 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2361 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2362 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2363 1-126-934-11 ELECT 220MF 20% 16V
C2364 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C2366 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C2367 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2368 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2371 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C2372 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2374 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C2377 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2378 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2380 1-163-145-00 CERAMIC CHIP 0.0015MF 5% 50V
C2381 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2382 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2383 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2385 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C2387 1-136-250-11 FILM 0.001MF 2% 100V
C2388 1-136-479-11 FILM 0.001MF 1% 100V
C2389 1-163-085-00 CERAMIC CHIP 2PF 0.25PF 50V
C2390 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2391 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2704 1-126-934-11 ELECT 220MF 20% 16V
C2705 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
< CONNECTOR >
CN2100 1-695-301-11 CONNECTOR, BOARD TO BOARD 40P
< FILTER >
FL2300 1-236-071-11 ENCAPSULATED COMPONENT
FL2301 1-233-767-21 FILTER
FL2302 1-236-071-11 ENCAPSULATED COMPONENT
FL2303 1-236-071-11 ENCAPSULATED COMPONENT
FL2308 1-233-736-21 FILTER, EMI
< IC >
IC2300 8-759-991-41 IC LM78L05ACZ
IC2301 8-759-295-09 IC TLC2932IPW
IC2302 8-759-257-59 IC TDA8755T-T
IC2303 8-759-438-64 IC SAA4952WP/V1
IC2304 8-759-546-02 IC SAA4995WP-V1-T3
IC2305 8-759-295-09 IC TLC2932IPW
*A-1620-112-A B1 Board, Complete
B1
To Next Page
