Sony Trinitron KV-28FC60 - J Board

http://cxema.ru
120
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< CAPACITOR >
C7150 1-126-969-11 ELECT 220MF 20% 50V
< CONNECTOR >
CN1800 *1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D7150 8-719-030-11 DIODE SLA-570KT3F
4-203-258-11 HOLDER, LED (D7150)
< IC >
IC7150 8-749-014-59 IC TSOP1740KS1
< RESISTOR >
R7150 1-247-815-91 CARBON 220 5% 1/4W
R7151 1-249-411-11 CARBON 330 5% 1/4W
< CAPACITOR >
C7825 1-137-372-11 FILM 0.022MF 5% 50V
C7826 1-137-372-11 FILM 0.022MF 5% 50V
< CONNECTOR >
CN1893 *1-564-519-11 PLUG, CONNECTOR 4P
< JACK >
J7825 1-785-448-21 JACK
< COIL >
L7825 1-414-183-41 INDUCTOR 10UH
L7826 1-414-183-41 INDUCTOR 10UH
< CAPACITOR >
C7800 1-101-810-00 CERAMIC 100PF 5% 500V
C7801 1-101-810-00 CERAMIC 100PF 5% 500V
< CONNECTOR >
CN1803 *1-564-522-11 PLUG, CONNECTOR 7P
< JACK >
J7800 1-793-529-11 TERMINAL BLOCK, S
< RESISTOR >
R7800 1-535-303-00 LEAD, JUMPER (5.0MM)
R7801 1-249-417-11 CARBON 1K 5% 1/4W
R7802 1-247-895-91 CARBON 470K 5% 1/4W
R7803 1-247-895-91 CARBON 470K 5% 1/4W
R7805 1-249-417-11 CARBON 1K 5% 1/4W
< CAPACITOR >
C7961 1-101-005-00 CERAMIC 0.022MF 50V
C7962 1-101-005-00 CERAMIC 0.022MF 50V
< CONNECTOR >
CN7101 1-573-299-21 CONNECTOR, BOARD TO BOARD 10P
CN7977 *1-564-519-11 PLUG, CONNECTOR 4P
CN7988 *1-564-519-11 PLUG, CONNECTOR 4P
CN7990 *1-564-518-11 PLUG, CONNECTOR 3P
< JACK >
J7952 1-537-339-11 TERMINAL BOARD
< COIL >
L7954 1-414-761-11 INDUCTOR 1UH
L7956 1-414-761-11 INDUCTOR 1UH
< CAPACITOR >
C8105 1-126-933-11 ELECT 100MF 20% 16V
C8106 1-126-933-11 ELECT 100MF 20% 16V
C8107 1-126-935-11 ELECT 470MF 20% 16V
C8108 1-126-933-11 ELECT 100MF 20% 16V
C8109 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C8110 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C8111 1-126-933-11 ELECT 100MF 20% 16V
C8112 1-128-551-11 ELECT 22MF 20% 25V
C8144 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C8145 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C8200 1-104-664-11 ELECT 47MF 20% 16V
C8201 1-163-241-11 CERAMIC CHIP 39PF 5% 50V
C8202 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C8203 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C8204 1-164-506-11 CERAMIC CHIP 4.7MF 16V
*A-1646-194-A H3 Board, Complete
*A-1646-195-A H4 Board, Complete
*A-1648-026-A U Board, Complete
*A-1651-119-A J Board, Complete
*A-1646-193-A H2 Board, Complete
H2 H3 H4 U J
