104
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R1407 1-216-025-91 RES,CHIP 100 5% 1/10W
R1408 1-216-025-91 RES,CHIP 100 5% 1/10W
R1409 1-216-025-91 RES,CHIP 100 5% 1/10W
R1410 1-216-025-91 RES,CHIP 100 5% 1/10W
R1411 1-216-295-91 SHORT 0
R1412 1-216-295-91 SHORT 0
R1601 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1602 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R1603 1-216-025-91 RES,CHIP 100 5% 1/10W
R1605 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1609 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1610 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1615 1-216-025-91 RES,CHIP 100 5% 1/10W
R1616 1-216-304-11 RES,CHIP 3.3 5% 1/10W
R1618 1-216-295-91 SHORT 0
R1621 1-216-027-00 RES,CHIP 120 5% 1/10W
R1622 1-216-029-00 RES,CHIP 150 5% 1/10W
R1625 1-216-295-91 SHORT 0
< TUNER >
TU1326 1-693-340-11 TUNER/VIF (FR)
< CAPACITOR >
C9100 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9101 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9102 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9104 1-104-664-11 ELECT 47MF 20% 25V
C9105 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9110 1-165-321-11 CERAMIC CHIP 0.68MF 10% 16V
C9111 1-164-157-11 CERAMIC CHIP 0.068MF 10% 25V
C9112 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9113 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9114 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9115 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9117 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9118 1-104-664-11 ELECT 47MF 20% 25V
C9119 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C9121 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9122 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9123 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9124 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9125 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9126 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C9127 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C9128 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C9129 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C9130 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C9131 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C9132 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9400 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9500 1-104-664-11 ELECT 47MF 20% 25V
C9502 1-104-664-11 ELECT 47MF 20% 25V
C9503 1-126-964-11 ELECT 10MF 20% 50V
C9504 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9505 1-104-665-11 ELECT 100MF 20% 25V
C9506 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9507 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9508 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9509 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9510 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9511 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9512 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9513 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C9514 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C9515 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C9516 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9517 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C9518 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C9519 1-126-964-11 ELECT 10MF 20% 50V
C9520 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN9101 1-695-301-11 CONNECTOR, BOARD TO BOARD 40P
< DIODE >
D9100 8-719-988-61 DIODE 1SS355TE-17
D9101 8-719-988-61 DIODE 1SS355TE-17
D9102 8-719-988-61 DIODE 1SS355TE-17
D9103 8-719-988-61 DIODE 1SS355TE-17
D9104 8-719-069-57 DIODE UDZS-TE17-6.8B
D9105 8-719-914-43 DIODE DAN202K
D9109 8-719-105-91 DIODE RD5.6M-B2
< FILTER >
FL9101 1-236-071-11 ENCAPSULATED COMPONENT
FL9500 1-236-071-11 ENCAPSULATED COMPONENT
FL9501 1-236-071-11 ENCAPSULATED COMPONENT
< IC >
IC9100 8-759-988-13 IC LM393PS
IC9104 8-759-259-18 IC MB3793-42PNF
IC9105 8-759-544-30 IC SAB-C161R1-LM
*A-1634-047-A M Board, Complete
A
M
To Next Page
