103
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
IC1604 8-759-544-13 IC KA78R09TU
< COIL >
L1126 1-416-857-11 INDUCTOR 65UH
L1127 1-414-158-11 INDUCTOR 2.2UH
L1128 1-414-158-11 INDUCTOR 2.2UH
L1151 1-416-857-11 INDUCTOR 65UH
L1152 1-414-158-11 INDUCTOR 2.2UH
L1153 1-414-158-11 INDUCTOR 2.2UH
L1326 1-414-183-41 INDUCTOR 10UH
< TRANSISTOR >
Q1100 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1204 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1226 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1227 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1229 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q1326 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1327 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1328 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1329 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1400 8-729-046-47 TRANSISTOR KSC2500-BTA
Q1601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1626 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
JR1069 1-216-190-91 RES, CHIP 470 5% 1/8W
JR1204 1-216-296-91 SHORT 0
JR1601 1-216-296-91 SHORT 0
R1001 1-216-295-91 SHORT 0
R1002 1-216-295-91 SHORT 0
R1003 1-216-295-91 SHORT 0
R1004 1-216-295-91 SHORT 0
R1005 1-216-295-91 SHORT 0
R1006 1-216-295-91 SHORT 0
R1100 1-216-025-91 RES,CHIP 100 5% 1/10W
R1101 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1103 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1104 1-216-296-91 SHORT 0
R1126 1-216-631-11 METAL CHIP 150 0.50% 1/10W
R1127 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1128 1-216-041-00 RES,CHIP 470 5% 1/10W
R1151 1-216-631-11 METAL CHIP 150 0.50% 1/10W
R1152 1-216-075-00 RES,CHIP 12K 5% 1/10W
R1153 1-216-041-00 RES,CHIP 470 5% 1/10W
R1176 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R1177 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R1178 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R1179 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R1180 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1181 1-216-045-00 RES,CHIP 680 5% 1/10W
R1182 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1183 1-216-045-00 RES,CHIP 680 5% 1/10W
R1184 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1185 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1201 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1202 1-216-083-00 RES,CHIP 27K 5% 1/10W
R1203 1-216-083-00 RES,CHIP 27K 5% 1/10W
R1204 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R1205 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1206 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1208 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1209 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1210 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1227 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1228 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1229 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1230 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R1232 1-216-295-91 SHORT 0
R1233 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1326 1-216-025-91 RES,CHIP 100 5% 1/10W
R1327 1-216-025-91 RES,CHIP 100 5% 1/10W
R1328 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1329 1-216-025-91 RES,CHIP 100 5% 1/10W
R1330 1-216-041-00 RES,CHIP 470 5% 1/10W
R1331 1-216-041-00 RES,CHIP 470 5% 1/10W
R1332 1-216-041-00 RES,CHIP 470 5% 1/10W
R1333 1-216-075-00 RES,CHIP 12K 5% 1/10W
R1334 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1335 1-216-025-91 RES,CHIP 100 5% 1/10W
R1336 1-216-041-00 RES,CHIP 470 5% 1/10W
R1337 1-216-041-00 RES,CHIP 470 5% 1/10W
R1338 1-216-001-00 RES,CHIP 10 5% 1/10W
R1339 1-216-041-00 RES,CHIP 470 5% 1/10W
R1340 1-216-043-91 RES,CHIP 560 5% 1/10W
R1342 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1400 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R1401 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1403 1-216-295-91 SHORT 0
R1404 1-216-295-91 SHORT 0
R1405 1-216-025-91 RES,CHIP 100 5% 1/10W
