101
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R2411 1-216-037-00 RES,CHIP 330 5% 1/10W
R2412 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R2413 1-216-664-11 METAL CHIP 3.6K 0.50% 1/10W
R2415 1-216-295-91 SHORT 0
R2701 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2702 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2703 1-216-025-91 RES,CHIP 100 5% 1/10W
R2704 1-216-025-91 RES,CHIP 100 5% 1/10W
R2705 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2706 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2711 1-216-001-00 RES,CHIP 10 5% 1/10W
R2713 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2714 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2715 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2716 1-216-025-91 RES,CHIP 100 5% 1/10W
R2717 1-216-295-91 SHORT 0
R2718 1-216-295-91 SHORT 0
R2719 1-216-295-91 SHORT 0
R2720 1-216-295-91 SHORT 0
R2721 1-216-295-91 SHORT 0
R2722 1-216-295-91 SHORT 0
R2723 1-216-027-00 RES,CHIP 120 5% 1/10W
R2724 1-216-295-91 SHORT 0
R2725 1-216-009-91 RES,CHIP 22 5% 1/10W
R2726 1-216-295-91 SHORT 0
R2727 1-216-295-91 SHORT 0
R2728 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2734 1-216-295-91 SHORT 0
R2735 1-216-021-00 RES,CHIP 68 5% 1/10W
R2736 1-216-295-91 SHORT 0
R2738 1-216-025-91 RES,CHIP 100 5% 1/10W
< CRYSTAL >
X2300 1-579-175-11 VIBRATOR, CERAMIC
*4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CAPACITOR >
C7626 £ 1-136-527-12 FILM 0.47MF 20% 300V
< CONNECTOR >
CN7611 £ *1-580-844-11 PIN, CONNECTOR (POWER)
CN7622 1-695-915-11 TAB (CONTACT)
CN7633 £ *1-580-843-11 PIN, CONNECTOR (POWER)
< FUSE >
F7626 £ 1-532-299-00 FUSE
£ *1-533-725-11 HOLDER, FUSE (F7626)
< FILTER >
LF7627 £ 1-433-488-11 TRANSFORMER, LINE FILTER
< RESISTOR >
R7626 £ 1-202-885-91 SOLID 1M 20% 1/2W
R7627 £ 1-220-797-11 CEMENTED 0.47 5% 10W F
< VARISTOR >
VDR7626 £ 1-801-268-51 VARISTOR ERZV14D471
< CONNECTOR >
CN7700 £ *1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
CN7733 £ *1-580-843-11 PIN, CONNECTOR (POWER)
< SWITCH >
S7751 £ 1-571-433-21 SWITCH, PUSH (AC POWER)
4-382-854-11 SCREW (M3X10), P, SW (+)
*4-931-401-01 HEAT SINK, V.OUT
< CAPACITOR >
C1100 1-104-664-11 ELECT 47MF 20% 25V
C1101 1-126-943-11 ELECT 2200MF 20% 25V
C1126 1-162-568-11 CERAMIC CHIP 0.33MF 10% 16V
C1127 1-137-194-81 FILM 0.47MF 5% 50V
C1128 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C1129 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C1130 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C1131 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1132 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1133 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1134 1-126-961-11 ELECT 2.2MF 20% 50V
C1135 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1136 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1137 1-126-953-11 ELECT 2200MF 20% 35V
C1138 1-126-953-11 ELECT 2200MF 20% 35V
C1139 1-104-329-11 CERAMIC CHIP 0.1MF 10% 50V
C1140 1-111-142-91 ELECT 150MF 20% 63V
*A-1624-083-A F1 Board, Complete
*A-1624-084-A F2 Board, Complete
*A-1631-051-A A Board, Complete
AB1 F1 F2
