106
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R9197 1-216-073-00 RES,CHIP 10K 5% 1/10W
R9500 1-216-295-91 SHORT 0
R9501 1-216-295-91 SHORT 0
R9502 1-216-295-91 SHORT 0
R9504 1-216-041-00 RES,CHIP 470 5% 1/10W
R9505 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R9506 1-216-073-00 RES,CHIP 10K 5% 1/10W
R9507 1-216-097-91 RES,CHIP 100K 5% 1/10W
R9508 1-216-017-91 RES,CHIP 47 5% 1/10W
R9509 1-216-049-91 RES,CHIP 1K 5% 1/10W
R9510 1-216-017-91 RES,CHIP 47 5% 1/10W
R9511 1-216-049-91 RES,CHIP 1K 5% 1/10W
R9512 1-216-017-91 RES,CHIP 47 5% 1/10W
R9513 1-216-017-91 RES,CHIP 47 5% 1/10W
R9514 1-216-017-91 RES,CHIP 47 5% 1/10W
R9515 1-216-295-91 SHORT 0
R9516 1-216-295-91 SHORT 0
R9517 1-216-295-91 SHORT 0
R9518 1-216-049-91 RES,CHIP 1K 5% 1/10W
R9519 1-216-039-00 RES,CHIP 390 5% 1/10W
R9520 1-216-039-00 RES,CHIP 390 5% 1/10W
R9521 1-216-039-00 RES,CHIP 390 5% 1/10W
R9522 1-216-295-91 SHORT 0
R9523 1-216-295-91 SHORT 0
R9524 1-216-295-91 SHORT 0
R9525 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R9526 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R9527 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R9528 1-216-025-91 RES,CHIP 100 5% 1/10W
R9529 1-216-025-91 RES,CHIP 100 5% 1/10W
R9530 1-216-025-91 RES,CHIP 100 5% 1/10W
R9531 1-216-295-91 SHORT 0
< CRYSTAL >
X9101 1-781-107-21 VIBRATOR, SERAMIC
X9500 1-760-551-21 VIBRATOR, CERAMIC
4-382-854-11 SCREW (M3X10), P, SW (+)
< CAPACITOR >
C5301 1-102-129-00 CERAMIC 0.01MF 10% 50V
C5302 1-128-528-11 ELECT 470MF 20% 16V
C5304 1-107-666-11 ELECT 1MF 20% 350V
C5305 1-136-207-11 FILM 0.047MF 10% 400V
C5306 1-102-157-00 CERAMIC 560PF 10% 500V
C5325 1-102-959-91 CERAMIC 22PF 5% 50V
C5326 1-102-157-00 CERAMIC 560PF 10% 500V
C5327 1-102-129-00 CERAMIC 0.01MF 10% 50V
C5328 1-128-528-11 ELECT 470MF 20% 16V
C5329 1-107-967-11 ELECT 1MF 20% 400V
C5350 1-107-907-11 ELECT 22MF 20% 50V
C5352 1-102-157-00 CERAMIC 560PF 10% 500V
C5353 1-102-129-00 CERAMIC 0.01MF 10% 50V
C5354 1-128-528-11 ELECT 470MF 20% 16V
C5355 1-107-666-11 ELECT 1MF 20% 350V
C5356 1-136-207-11 FILM 0.047MF 10% 400V
C5375 1-107-902-11 ELECT 1MF 20% 50V
C5377 1-162-115-00 CERAMIC 330PF 10% 2KV
C5378 1-162-116-00 CERAMIC 680PF 10% 2KV
C5379 1-162-114-00 CERAMIC 0.0047MF 2KV
C5380 1-107-652-11 ELECT 10MF 20% 250V
C5381 1-162-116-00 CERAMIC 680PF 10% 2KV
C5382 1-162-114-00 CERAMIC 0.0047MF 2KV
< CONNECTOR >
CN5400 *1-564-511-11 PLUG, CONNECTOR 8P
CN5511 1-695-915-11 TAB (CONTACT)
CN5600 1-508-766-00 PIN, CONNECTOR (5MM PITCH) 4P
< DIODE >
D5300 8-719-911-19 DIODE 1SS119-25
D5302 8-719-901-83 DIODE 1SS83
D5325 8-719-911-19 DIODE 1SS119-25
D5326 8-719-923-60 DIODE MTZJ-T-77-9.1A
D5327 8-719-901-83 DIODE 1SS83
D5350 8-719-911-19 DIODE 1SS119-25
D5351 8-719-991-33 DIODE 1SS133T-77
D5353 8-719-901-83 DIODE 1SS83
D5375 8-719-991-33 DIODE 1SS133T-77
D5376 8-719-991-33 DIODE 1SS133T-77
D5377 8-719-908-03 DIODE GP08D
D5378 8-719-921-88 DIODE MTZJ-13B
D5379 8-719-982-96 DIODE MTZJ-T-77-2.2A
D5380 8-719-982-96 DIODE MTZJ-T-77-2.2A
D5381 8-719-031-34 DIODE RGP02-20EG23
< IC >
IC5300 8-759-360-83 IC TDA6111Q/N4
IC5325 8-759-360-83 IC TDA6111Q/N4
IC5350 8-759-360-83 IC TDA6111Q/N4
*A-1638-132-A C Board, Complete
