112
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< CAPACITOR >
C6814 1-117-641-11 FILM 7500PF 3% 1.2KV
C6815 1-117-836-11 FILM 6800PF 3% 1.5KV
C6825 1-115-514-11 FILM 0.22MF 5% 250V
C6826 1-115-520-11 FILM 0.68MF 5% 250V
< RESISTOR >
R6810 1-215-920-11 METAL OXIDE 3.3K 5% 3W F
R6836 1-249-432-21 CARBON 18K 5% 1/4W
R6856 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R6857 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R6858 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R6859 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R6897 1-215-485-00 METAL 470K 1% 1/4W
< CAPACITOR >
C6814 1-117-640-11 FILM 6800PF 3% 1.2KV
C6815 1-117-835-11 FILM 6200PF 3% 1.5KV
C6825 1-117-662-11 FILM 0.18MF 5% 250V
C6826 1-115-579-11 FILM 0.56MF 5% 250V
< RESISTOR >
R6810 1-216-484-00 METAL OXIDE 3.9K 5% 3W
R6836 1-249-431-11 CARBON 15K 5% 1/4W
R6856 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R6857 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R6858 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R6859 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R6897 1-215-489-11 METAL 680K 1% 1/4W
< CAPACITOR >
C4316 1-104-664-11 ELECT 47MF 20% 25V
C4317 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4318 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4319 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4320 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4321 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4322 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4324 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4325 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C4329 1-126-963-11 ELECT 4.7MF 20% 50V
C4330 1-137-581-11 FILM 0.1MF 5% 100V
C4331 1-126-959-11 ELECT 0.47MF 20% 50V
C4332 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4333 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4334 1-126-967-11 ELECT 47MF 20% 50V
C4336 1-126-967-11 ELECT 47MF 20% 50V
C4338 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4340 1-126-967-11 ELECT 47MF 20% 50V
C4342 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C4343 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4344 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C4345 1-126-967-11 ELECT 47MF 20% 50V
C4346 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4347 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4348 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4349 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4350 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4351 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C4352 1-126-967-11 ELECT 47MF 20% 50V
C4353 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C4354 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C4355 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4356 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4357 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4358 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4359 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C4360 1-126-963-11 ELECT 4.7MF 20% 50V
C4362 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4363 1-126-967-11 ELECT 47MF 20% 50V
C4364 1-126-967-11 ELECT 47MF 20% 50V
C4366 1-163-059-91 CERAMIC CHIP 0.01MF 10% 50V
C4369 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4370 1-126-967-11 ELECT 47MF 20% 50V
C4371 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C4377 1-126-960-11 ELECT 1MF 20% 50V
C4379 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C4381 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN4101 1-695-301-11 CONNECTOR, BOARD TO BOARD 40P
CN4500 *1-564-511-11 PLUG, CONNECTOR 8P
CN4502 *1-568-878-51 PIN, CONNECTOR 3P
D Board Variant Parts KV-32FC60/32FC60/Z
*A-1640-348-A E Board, Complete
(KV-28FC60/28FC60/Z)
*A-1640-347-A E Board, Complete
(KV-32FC60/32FC60/Z)
E Board Common Parts
D Board Variant Parts KV-28FC60/28FC60/Z
D E
To Next Page
