123
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< CONNECTOR >
CN8101 1-695-302-11 CONNECTOR, BOARD TO BOARD 50P
CN8102 *1-564-518-11 PLUG, CONNECTOR 3P
CN8900 1-561-534-41 SOCKET, PIN 21P
CN8901 1-695-293-11 SOCKET 21P
CN8902 1-695-293-11 SOCKET 21P
< DIODE >
D8200 8-719-158-49 DIODE RD12SB2
D8201 8-719-158-49 DIODE RD12SB2
D8202 8-719-158-49 DIODE RD12SB2
D8203 8-719-158-49 DIODE RD12SB2
D8801 8-719-158-49 DIODE RD12SB2
D8802 8-719-158-49 DIODE RD12SB2
D8803 8-719-158-49 DIODE RD12SB2
D8804 8-719-158-49 DIODE RD12SB2
D8805 8-719-158-49 DIODE RD12SB2
D8806 8-719-158-49 DIODE RD12SB2
D8807 8-719-158-49 DIODE RD12SB2
D8808 8-719-158-49 DIODE RD12SB2
D8809 8-719-158-49 DIODE RD12SB2
D8810 8-719-158-49 DIODE RD12SB2
D8811 8-719-158-49 DIODE RD12SB2
D8812 8-719-158-49 DIODE RD12SB2
D8813 8-719-158-49 DIODE RD12SB2
D8814 8-719-158-49 DIODE RD12SB2
D8900 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8901 8-719-158-49 DIODE RD12SB2
D8902 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8903 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8904 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8905 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8906 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8907 8-719-158-49 DIODE RD12SB2
D8908 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8909 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8910 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8911 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8912 8-719-158-49 DIODE RD12SB2
D8913 8-719-158-49 DIODE RD12SB2
D8914 8-719-158-49 DIODE RD12SB2
D8915 8-719-158-49 DIODE RD12SB2
< FILTER >
FL8200 1-236-071-11 ENCAPSULATED COMPONENT
FL8201 1-233-764-21 FILTER
FL8203 1-236-071-11 ENCAPSULATED COMPONENT
FL8302 1-236-071-11 ENCAPSULATED COMPONENT
FL8304 1-236-071-11 ENCAPSULATED COMPONENT
FL8308 1-236-071-11 ENCAPSULATED COMPONENT
FL8500 1-236-071-11 ENCAPSULATED COMPONENT
FL8501 1-236-071-11 ENCAPSULATED COMPONENT
FL8502 1-233-765-21 FILTER
FL8503 1-233-768-21 FILTER
FL8504 1-233-766-21 FILTER
FL8700 1-236-071-11 ENCAPSULATED COMPONENT
FL8701 1-236-071-11 ENCAPSULATED COMPONENT
FL8801 1-236-071-11 ENCAPSULATED COMPONENT
FL8802 1-236-071-11 ENCAPSULATED COMPONENT
< IC >
IC8101 8-759-576-76 IC TDA2822D013TR
IC8151 8-752-072-94 IC CXA1875AM-T4
IC8200 8-759-544-10 IC MSP3410D-QA-B4
IC8201 8-759-701-36 IC NJM3403AM
IC8202 8-759-908-15 IC TL431CLP
IC8301 8-752-094-47 IC CXA2123Q-T6
IC8302 8-759-485-79 IC TC7SET08FU(TE85L)
IC8500 8-752-390-37 IC CXD2064Q-T6
IC8601 8-759-576-74 IC LF90CDT-TR
IC8602 8-759-576-72 IC LF50CDT-TR
IC8603 8-759-576-72 IC LF50CDT-TR
IC8604 8-759-576-72 IC LF50CDT-TR
IC8700 8-752-390-35 IC CXD2057M-T6
IC8801 8-752-090-38 IC CXA2129Q-TL
IC8802 8-759-385-76 IC MC14052BDR2
< JACK >
J8901 1-774-747-11 JACK BLOCK, PIN
< COIL >
L8150 1-414-757-11 INDUCTOR 100UH
L8200 1-412-006-42 INDUCTOR CHIP 10UH
L8201 1-412-064-11 INDUCTOR CHIP 100UH
L8801 1-412-751-11 INDUCTOR 18UH
< TRANSISTOR >
Q8100 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8156 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8157 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8200 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
