— 79 —
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
11 1-556-945-21 CABLE, P-P (KV-32FV15/32XBR250/34FV15/
34FV15C/34FV15K/34FV15T/34FX250C Only)
12 8-598-414-10 ANTENNA CHANGER AS-2F
(KV-32FV15/32XBR250/34FV15/34FV15C/
34FV15K/34FV15T/34FX250C Only)
13 * A-1394-947-A UX BOARD, COMPLETE
(KV-32XBR250 Only)
13 * A-1394-948-A UX BOARD, COMPLETE KV-34FX250C Only)
13 * A-1394-938-A UY BOARD, COMPLETE
(KV-32FS10/34FV10 Only)
13 * A-1394-943-A UY BOARD, COMPLETE
(KV-32FV15 Only)
13 * A-1394-944-A UY BOARD, COMPLETE (KV-34FV15/
34FV15C/34FV15K/34FV15T Only)
14 3-696-606-02 HINGE, VI
15 * A-1316-397-A G BOARD, COMPLETE (KV-32FS10/32FV15/
32XBR250 Only)
15 * A-1316-423-A G BOARD, COMPLETE (KV-34FV15T Only)
15 * A-1316-470-A GA BOARD, COMPLETE (KV-34FV10/34FV15/
34FV15C/34FV15K/34FX250C Only)
Les composants identifies per un trame et une marque
!
sont critiques pour
la securite. Ne les remplacer que par une piece portant le numero specifie.
The components identified by shading and "
!
" are critical
for safety. Replace only with specified part number.
16
!
1-769-796-71 CORD, POWER (WITH CONNECTOR)
(KV-34FV15C/34FX250C Only)
16
!
1-775-468-11 CORD, POWER (WITH CONNECTOR)
(KV-34FV15K Only)
16
!
1-790-315-21 CORD, AC POWER (WITH CONNECTOR)
(KV-34FV10/34FV15 Only)
16
!
1-790-317-21 CORD, AC POWER (WITH CONNECTOR)
(KV-32FS10/32FV15/32XBR250/34FV15T Only)
17 * 4-068-988-01 BAFFLE, SPEAKER
18 1-529-336-11 SPEAKER (1-WAY) (KV-32FS10/
32FV15/34FV15K/34FV15T Only)
18 1-529-358-11 SPEAKER (2-WAY) (KV-32XBR250/
34FV10/34FV15/34FV15C/34FX250C Only)
19 * 4-068-987-01 BOX, SPEAKER
20 4-069-000-01 COVER, REAR (KV-32FV15/32XBR250/
34FV15T/34FX250C Only)
20 4-069-000-21 COVER, REAR (KV-32FS10/34FV10/34FV15,
34FV15C/34FV15K Only)
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
