— 82 —
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont
critiques pour la securite. Ne les remplacer que par une piece
portant le numero specifie.
The components identified by shading and "
¡¡
¡¡
¡" mark are
critical for safety. Replace only with specified part number.
60
!
8-735-080-61 ITC 38RSN-A1E (KV-38FX250C Only) 61-62
61
!
8-735-047-05 CRT 34RSN (KV-32FS10/34FV10/34FV15/
34FV15C/34FV15K/34FV15T Only)
62
!
8-451-499-21 DY Y34RSA-X (KV-32FS10/34FV10/34FV15/
34FV15C/34FV15K/34FV15T Only)
63 2-163-920-01 PLATE, TLH CORRECTION
(KV-32FS10/34FV10/34FV15/34FV15C/
34FV15K/34FV15T Only)
64
!
8-453-007-41 NA324-M4 (KV-32FS10/34FV10/34FV15/
34FV15C/34FV15K/34FV15T Only)
65 * A-1375-187-A WA BOARD, MOUNTED (KV-32FS10/32FV15/
32XBR250/34FV10/34FV15/34FV15K/
34FV15T/34FX250C
Only)
65 * A-1375-191-A WA BOARD, MOUNTED (KV-36FS10/36FV15/
36XBR250/36XBR250C/38FV15K/38FX250/
38FX250C/38FX250T Only)
66 *A-1331-942-A C BOARD, COMPLETE
67 4-053-005-01 SPACER, DY (KV-32FS10/34FV10/34FV15/
34FV15C/34FV15K/34FV15T Only)
68 1-452-896-11 COIL, NA ROTATION (KV-32FS10/34FV15/
34FV15C/34FV15K/34FV15T Only)
69 3-704-372-31 HOLDER, HV CABLE
70 4-036-329-01 SPRING (B), TENSION
71
!
1-419-163-11 COIL, DEMAGNETIZATION
(KV-34FV10/34FV15/34FV15C/34FV15K/
34FX250C Only)
71
!
1-419-193-11 COIL, DEMAGNETIZATION
(KV-38FV15K/38FX250/38FX250C Only)
71
!
1-416-827-11 COIL, DEMAGNETIZATION
(KV-32FS10/32FV15/32XBR250/34FV15T Only)
71
!
1-416-828-11 COIL, DEMAGNETIZATION
(KV-36FS10/36FV15/36XBR250/
38FX250T Only)
72 4-065-895-02 HOLDER, DGC
73 4-046-765-01 SCREW, TAPPING (7) +CROWN WASHER
74 1-452-094-00 DISC, CIRCULAR (KV-32FS10/34FV10/
34FV15/34FV15C/34FV15K/34FV15T Only)
75 1-452-032-00 MAGNET, DISC
(KV-32FS10/34FV10/34FV15/34FV15C,
34FV15K/34FV15T Only)
76 4-062-047-01 PIECE A (110), CONV CORRECT
(KV-32FS10/34FV10/34FV15/34FV15C/
34FV15K/34FV15T Only)
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
