— 116 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
Q238 8-729-216-22 TRANSISTOR 2SA1162-G
Q239 8-729-216-22 TRANSISTOR 2SA1162-G
Q246 8-729-422-27 TRANSISTOR 2SD601A-Q
Q262 8-729-216-22 TRANSISTOR 2SA1162-G
Q263 8-729-216-22 TRANSISTOR 2SA1162-G
Q264 8-729-216-22 TRANSISTOR 2SA1162-G
Q265 8-729-422-27 TRANSISTOR 2SD601A-Q
Q267 8-729-216-22 TRANSISTOR 2SA1162-G
Q1051 8-729-216-22 TRANSISTOR 2SA1162-G
(KV-32FS10/34FV10/36FS10/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
Q1201 8-729-216-22 TRANSISTOR 2SA1162-G
Q1202 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1203 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1204 8-729-216-22 TRANSISTOR 2SA1162-G
Q1205 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-32FS10/34FV10/36FS10/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
Q1206 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1207 8-729-216-22 TRANSISTOR 2SA1162-G
Q1208 8-729-216-22 TRANSISTOR 2SA1162-G
Q2003 8-729-216-22 TRANSISTOR 2SA1162-G
Q2004 8-729-216-22 TRANSISTOR 2SA1162-G
Q2005 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2006 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2007 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2009 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2010 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2014 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2018 8-729-216-22 TRANSISTOR 2SA1162-G
Q2019 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R201 1-216-022-00 RES, CHIP 75 5% 1/10W
R202 1-216-022-00 RES, CHIP 75 5% 1/10W
R203 1-216-022-00 RES, CHIP 75 5% 1/10W
R204 1-216-113-00 RES, CHIP 470K 5% 1/10W
R205 1-216-113-00 RES, CHIP 470K 5% 1/10W
R206 1-216-295-91 SHORT
R207 1-216-295-91 SHORT
R208 1-216-295-91 SHORT
R209 1-216-089-91 RES, CHIP 47K 5% 1/10W
R210 1-216-081-00 RES, CHIP 22K 5% 1/10W
R211 1-216-089-91 RES, CHIP 47K 5% 1/10W
R212 1-216-081-00 RES, CHIP 22K 5% 1/10W
R213 1-216-089-91 RES, CHIP 47K 5% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R214 1-216-081-00 RES, CHIP 22K 5% 1/10W
R218 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R219 1-216-049-91 RES, CHIP 1K 5% 1/10W
R220 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R221 1-208-774-11 RES, CHIP 470 0.50% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R222 1-216-049-91 RES, CHIP 1K 5% 1/10W
R223 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R225 1-216-025-91 RES, CHIP 100 5% 1/10W
R226 1-216-025-91 RES, CHIP 100 5% 1/10W
R228 1-216-049-91 RES, CHIP 1K 5% 1/10W
R229 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R230 1-216-089-91 RES, CHIP 47K 5% 1/10W
R231 1-216-022-00 RES, CHIP 75 5% 1/10W
R232 1-216-022-00 RES, CHIP 75 5% 1/10W
R233 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R234 1-216-022-00 RES, CHIP 75 5% 1/10W
R235 1-216-113-00 RES, CHIP 470K 5% 1/10W
R236 1-216-113-00 RES, CHIP 470K 5% 1/10W
R237 1-216-022-00 RES, CHIP 75 5% 1/10W
R238 1-216-113-00 RES, CHIP 470K 5% 1/10W
R239 1-216-113-00 RES, CHIP 470K 5% 1/10W
R241 1-216-113-00 RES, CHIP 470K 5% 1/10W
R242 1-216-049-91 RES, CHIP 1K 5% 1/10W
R243 1-216-113-00 RES, CHIP 470K 5% 1/10W
R244 1-216-049-91 RES, CHIP 1K 5% 1/10W
R245 1-216-022-00 RES, CHIP 75 5% 1/10W
R246 1-216-113-00 RES, CHIP 470K 5% 1/10W
R247 1-216-113-00 RES, CHIP 470K 5% 1/10W
R248 1-216-113-00 RES, CHIP 470K 5% 1/10W
R249 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R250 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R251 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R252 1-216-049-91 RES, CHIP 1K 5% 1/10W
R254 1-216-049-91 RES, CHIP 1K 5% 1/10W
R256 1-216-295-91 SHORT
R257 1-216-049-91 RES, CHIP 1K 5% 1/10W
R258 1-216-025-91 RES, CHIP 100 5% 1/10W
R259 1-216-049-91 RES, CHIP 1K 5% 1/10W
R260 1-216-025-91 RES, CHIP 100 5% 1/10W
R261 1-216-025-91 RES, CHIP 100 5% 1/10W
R262 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R263 1-216-025-91 RES, CHIP 100 5% 1/10W
R264 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R265 1-216-025-91 RES, CHIP 100 5% 1/10W
R266 1-216-025-91 RES, CHIP 100 5% 1/10W
R267 1-216-025-91 RES, CHIP 100 5% 1/10W
R268 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R269 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R270 1-216-049-91 RES, CHIP 1K 5% 1/10W
R271 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R272 1-216-025-91 RES, CHIP 100 5% 1/10W
R273 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R274 1-216-049-91 RES, CHIP 1K 5% 1/10W
R275 1-216-025-91 RES, CHIP 100 5% 1/10W
R276 1-216-295-91 SHORT
R278 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R279 1-216-025-91 RES, CHIP 100 5% 1/10W
R280 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
