REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
UY
R281 1-216-025-91 RES, CHIP 100 5% 1/10W
R282 1-216-025-91 RES, CHIP 100 5% 1/10W
R283 1-216-049-91 RES, CHIP 1K 5% 1/10W
R284 1-216-033-00 RES, CHIP 220 5% 1/10W
R285 1-216-033-00 RES, CHIP 220 5% 1/10W
R286 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R287 1-216-025-91 RES, CHIP 100 5% 1/10W
R288 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R289 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R290 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R291 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R292 1-216-295-91 SHORT
R293 1-216-025-91 RES, CHIP 100 5% 1/10W
R294 1-216-077-00 RES, CHIP 15K 5% 1/10W
R295 1-216-025-91 RES, CHIP 100 5% 1/10W
R296 1-216-025-91 RES, CHIP 100 5% 1/10W
R297 1-216-025-91 RES, CHIP 100 5% 1/10W
R298 1-216-295-91 SHORT
R300 1-216-025-91 RES, CHIP 100 5% 1/10W
R301 1-216-049-91 RES, CHIP 1K 5% 1/10W
R302 1-216-295-91 SHORT
R902 1-249-405-11 CARBON 100 5% 1/4W
R921 1-249-405-11 CARBON 100 5% 1/4W
R923 1-249-405-11 CARBON 100 5% 1/4W
R925 1-249-405-11 CARBON 100 5% 1/4W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R926 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1055 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1056 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1057 1-216-025-91 RES, CHIP 100 5% 1/10W
R1058 1-216-025-91 RES, CHIP 100 5% 1/10W
R1059 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1060 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1062 1-216-025-91 RES, CHIP 100 5% 1/10W
R1063 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1064 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1065 1-216-025-91 RES, CHIP 100 5% 1/10W
R1070 1-216-025-91 RES, CHIP 100 5% 1/10W
R1205 1-216-295-91 SHORT
R1207 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R1209 1-216-295-91 SHORT
R1210 1-216-295-91 SHORT
R1215 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R1216 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1217 1-216-091-00 RES, CHIP 56K 5% 1/10W
R1218 1-216-295-91 SHORT
R1219 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1220 1-216-013-00 RES, CHIP 33 5% 1/10W
R1221 1-216-121-91 RES, CHIP 1M 5% 1/10W
R1222 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1223 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1224 1-216-089-91 RES, CHIP 47K 5% 1/10W
R1225 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1227 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1228 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R1229 1-216-121-91 RES, CHIP 1M 5% 1/10W
R1230 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1231 1-216-295-91 SHORT
R1233 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1234 1-216-091-00 RES, CHIP 56K 5% 1/10W
R1235 1-216-013-00 RES, CHIP 33 5% 1/10W
R1236 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1237 1-216-089-91 RES, CHIP 47K 5% 1/10W
R1238 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1239 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R1242 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1243 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1244 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1245 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1260 1-216-295-91 SHORT
R1263 1-216-295-91 SHORT
R1264 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1265 1-216-001-00 RES, CHIP 10 5% 1/10W
R1266 1-216-041-00 RES, CHIP 470 5% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R1267 1-216-025-91 RES, CHIP 100 5% 1/10W
R1268 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1269 1-216-041-00 RES, CHIP 470 5% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R1270 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1271 1-216-001-00 RES, CHIP 10 5% 1/10W
R1272 1-216-655-11 RES, CHIP 1.5K 0.50% 1/10W
R1273 1-208-788-11 RES, CHIP 1.8K 0.50% 1/10W
R1274 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1276 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1277 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-32FV15/36FV1534FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R1279 1-216-025-91 RES, CHIP 100 5% 1/10W
R1284 1-216-295-91 SHORT
R1287 1-216-295-91 SHORT
R1288 1-216-295-91 SHORT
R1289 1-216-295-91 SHORT
R1290 1-216-295-91 SHORT
R1291 1-216-295-91 SHORT
R1292 1-216-295-91 SHORT
R1293 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1294 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1295 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1300 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1304 1-216-041-00 RES, CHIP 470 5% 1/10W
R1305 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R1306 1-216-025-91 RES, CHIP 100 5% 1/10W
R1307 1-216-041-00 RES, CHIP 470 5% 1/10W
R1308 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R1309 1-216-025-91 RES, CHIP 100 5% 1/10W
R2015 1-216-081-00 RES, CHIP 22K 5% 1/10W
R2016 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R2017 1-216-295-91 SHORT
