http://cxema.ru
– 10 –
KV-G21MW3/G21QW3
RM-869
2-1. REAR COVER REMOVAL
2-2. A BOARD REMOVAL
2-3. SERVICE POSITION
SECTION 2
DISASSEMBLY
Four screws
(BVTP 4×16)
1
2
Two screws
(BVTP 4×16)
Lever
Lever
A board
