– 18 –
KV-G21MW3/G21QW3
RM-869
Use the same method for Items Number 00-40. Use 1 and 4 to
select the adjustment item, use 3 and 6 to adjust, write with
MUTING
, then execute the write with -.
WRITE
WRITE
GREEN0CVSF08
SERVICE
50
50
GREEN0CVSF08
Adjusted with
3 and 6 buttons
Written with
MUTING
Write executed with 0
GREEN
The WRITE display
will change back to
SERVICE.
(2nd line disappear
when written)
0CVSF08
00V3.2C058S/
060S
00V3.2C058S/
060S
Blank
4-2. ADJUSTMENT METHOD
Item Number 08
This explanation uses V-SHIFT as an example.
1. Select 08 V-SHIFT with the 1 and 4 buttons.
2. Raise/lower the data with the 3 and 6 buttons.
3. Select the optimum state. (The standard is 0F for PAL
reception.)
4. Write with the
MUTING
button.
5. Execute the writing with the - button. (The WRITE
display returns to green SERVICE.)
