– 48 –
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
KV-G21MW3/G21QW3
RM-869
D399 8-719-056-86 DIODE DTZ9.1
D401 8-719-421-40 DIODE MA77-TX (KV-G21MW3)
D402 8-719-911-19 DIODE 1SS119-25TD (KV-G21MW3)
D403 8-719-911-19 DIODE 1SS119-25TD
D513 8-719-109-84 DIODE RD5.1ES-T1B
D551 8-719-908-03 DIODE GP08DPKG23
D561 8-719-911-19 DIODE 1SS119-25TD
D591 8-719-911-19 DIODE 1SS119-25TD
D601 8-719-305-07 DIODE D4SB60L
D604 8-719-053-31 DIODE RU4DS
D606 8-719-052-52 DIODE S3L20UF4
D607 8-719-076-08 DIODE D1NL20-TA
D609 8-719-076-08 DIODE D1NL20-TA
D610 8-719-076-08 DIODE D1NL20-TA
D611 8-719-076-08 DIODE D1NL20-TA
D801 8-719-945-80 DIODE ERC06-15STP11
D802 8-719-979-85 DIODE RGP15J-6040G23
D851 8-719-302-43 DIODE RGP10GPKG23
D853 8-719-302-43 DIODE RGP10GPKG23
D855 8-719-302-43 DIODE RGP10GPKG23
D857 8-719-908-03 DIODE GP08DPKG23
D858 8-719-908-03 DIODE GP08DPKG23
D860 8-719-911-19 DIODE 1SS119-25TD
D901 1-810-039-11 LED UNIT
D1201 8-719-070-16 DIODE NNCD9.1A-T1
D1202 8-719-070-16 DIODE NNCD9.1A-T1
D1207 8-719-070-16 DIODE NNCD9.1A-T1
D1208 8-719-070-16 DIODE NNCD9.1A-T1
D1504 8-719-911-19 DIODE 1SS119-25TD
D1505 8-719-109-81 DIODE RD4.7ES-T1B
<FUSE>
F601 1-532-237-00 FUSE, TIME-LAG (BET) 3.15A/250V
<FERRITE BEAD>
FB101 1-410-397-21 FERRITE 1.1UH
FB102 1-410-397-21 FERRITE 1.1UH
FB103 1-410-397-21 FERRITE 1.1UH
FB601 1-410-397-21 FERRITE 1.1UH
FB603 1-410-397-21 FERRITE 1.1UH
FB610 1-410-397-21 FERRITE 1.1UH
FB612 1-410-397-21 FERRITE 1.1UH
FB801 1-410-397-21 FERRITE 1.1UH
<IC>
IC001 8-752-891-61 IC CXP85220A-060S (KV-G21MW3)
IC001 8-752-891-28 IC CXP85220A-058S (KV-G21QW3)
IC003 8-759-380-51 IC ST24C04FB6
IC004 8-759-180-30 HYB IC SBX3081-51(30)
IC100 8-759-157-40 DIODE HZT33-02TE
IC203 8-759-339-60 IC TA8248K
IC300 8-759-365-26 IC TDA8375A
IC351 8-759-565-20 IC TDA4665T/V5-118
IC354 8-759-430-79 IC TDA8395T
IC401 8-759-800-65 IC LA7910 (KV-G21MW3)
IC521 8-759-650-98 IC PQ09RD08
IC551 8-759-801-98 IC LA7830
IC601 8-749-014-00 IC STR-S6707N
IC602 8-749-921-89 IC SE115N
IC603 ! 8-749-010-64 PHOTO COUPLER PC123F2
IC801 8-759-151-08 IC UPC4558G2
IC1210 8-759-151-08 IC UPC4558G2
IC1211 8-759-711-23 IC NJM2234L
<JACK>
J251 1-770-786-21 JACK
J1201 1-779-849-11 JACK BLOCK, PIN 4P
J1202 1-779-205-11 JACK, PIN 2P
<CHIP CONDUCTOR>
JR050 1-216-295-91 SHORT 0
JR052 1-216-295-91 SHORT 0
JR101 1-216-295-91 SHORT 0
JR112 8-719-041-97 DIODE MA113-(TX)
JR113 1-216-295-91 SHORT 0
JR115 1-216-295-91 SHORT 0
JR116 1-216-295-91 SHORT 0
JR117 1-216-295-91 SHORT 0
JR118 1-216-295-91 SHORT 0
JR124 1-216-295-91 SHORT 0
JR125 1-216-295-91 SHORT 0
JR126 1-216-295-91 SHORT 0
JR251 1-216-295-91 SHORT 0
<COIL>
L001 1-408-591-11 INDUCTOR 1UH
L002 1-410-509-11 INDUCTOR 10UH
L003 1-408-605-31 INDUCTOR 15UH
L101 1-410-470-11 INDUCTOR 10UH
L301 1-408-602-31 INDUCTOR 8.2UH
L401 1-410-498-11 INDUCTOR 1.2UH
L402 1-410-510-11 INDUCTOR 12UH
L403 1-410-510-11 INDUCTOR 12UH (KV-G21MW3)
L404 1-410-508-11 INDUCTOR 8.2UH (KV-G21MW3)
L405 1-410-508-11 INDUCTOR 8.2UH (KV-G21MW3)
L406 1-410-507-11 INDUCTOR 6.8UH
L407 1-410-511-11 INDUCTOR 15UH (KV-G21MW3)
L408 1-410-500-11 INDUCTOR 1.8UH (KV-G21MW3)
L409 1-410-501-11 INDUCTOR 2.2UH (KV-G21MW3)
L410 1-410-501-11 INDUCTOR 2.2UH
L411 1-410-502-11 INDUCTOR 2.7UH (KV-G21MW3)
L802 1-412-527-11 INDUCTOR 15UH
L804 1-459-075-11 COIL,DYNAMIC CONVERSION CHOKE
L805 1-459-769-13 COIL, HORIZONTAL LINEARITY
L807 1-459-390-00 INDUCTOR 390UH
L808 1-412-552-11 INDUCTOR 2.2MH
L821 1-459-111-00 INDUCTOR 10MH
L850 1-408-947-00 INDUCTOR 2.2MH
