– 52 –
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
KV-G21MW3/G21QW3
RM-869
S902 1-571-532-21 SWITCH, TACTIL
S903 1-571-532-21 SWITCH, TACTIL
S904 1-571-532-21 SWITCH, TACTIL
S905 1-571-532-21 SWITCH, TACTIL
S906 1-571-532-21 SWITCH, TACTIL
<SPARK GAP>
SG801 1-519-422-11 GAP, SPARK
<#########>
SWF401 1-760-771-11 FILTER, SURFACE WAVE
<TRANSFORMER>
T601 ! 1-429-137-21 TRANSFORMER, CONVERTER (SRT)
T605 ! 1-424-682-11 TRANSFORMER, LINE FILTER
T801 1-437-195-11 TRANSFORMER, HORIZONTAL DRIVE
T851 ! 1-453-250-11 TRANSFORMER ASSY, FLYBACK (NX-1746//M3A)
<THERMISTOR>
THP601!1-808-059-31 THERMISTOR, POSITIVE
<TUNER>
TU101 ! 8-598-323-50 VSS TUNER BT-AG401
<CRYSTAL>
X101 1-577-358-21 VIBRATOR, CERAMIC
X300 1-411-752-11 COIL
X358 1-567-505-11 OSCILLATOR, CRYSTAL (KV-G21MW3)
X443 1-567-504-11 OSCILLATOR, CRYSTAL
*******************************************************************
* A-1331-688-A C BOARD MOUNTED
*******************
<CAPACITOR>
C701 1-162-114-00 CERAMIC 0.0047UF 2KV
C702 1-102-074-00 CERAMIC 0.001UF 10.00%50V
C703 1-107-651-11 ELECT 4.7UF 20.00%250V
C704 1-130-202-00 FILM 0.022UF 5.00% 400V
C708 1-102-114-00 CERAMIC 470PF 10.00%50V
C709 1-102-114-00 CERAMIC 470PF 10.00%50V
C710 1-102-114-00 CERAMIC 470PF 10.00%50V
C712 1-102-116-00 CERAMIC 680PF 10.00%50V
C713 1-102-116-00 CERAMIC 680PF 10.00%50V
C714 1-102-116-00 CERAMIC 680PF 10.00%50V
C716 1-126-933-11 ELECT 100UF 20.00%16V
C717 1-101-880-00 CERAMIC 47PF 5.00% 50V
C736 1-102-114-00 CERAMIC 470PF 10.00%50V
C737 1-102-114-00 CERAMIC 470PF 10.00%50V
C746 1-102-114-00 CERAMIC 470PF 10.00%50V
<CONNECTOR>
CN701 1-508-766-00 PIN, CONNECTOR (5MM PITCH) 4P
CN703 * 1-564-509-11 PLUG, CONNECTOR 6P
CN704 1-695-915-11 TAB (CONTACT)
<DIODE>
D701 8-719-911-19 DIODE 1SS119-25TD
D702 8-719-911-19 DIODE 1SS119-25TD
D703 8-719-911-19 DIODE 1SS119-25TD
D707 8-719-911-19 DIODE 1SS119-25TD
D708 8-719-911-19 DIODE 1SS119-25TD
D709 8-719-911-19 DIODE 1SS119-25TD
D710 8-719-911-19 DIODE 1SS119-25TD
D711 8-719-911-19 DIODE 1SS119-25TD
D712 8-719-911-19 DIODE 1SS119-25TD
D716 8-719-911-19 DIODE 1SS119-25TD
D717 8-719-929-15 DIODE RD9.1ES-T1B
<JACK>
J701 ! 1-251-732-11 SOCKET, CRT
<COIL>
L701 1-410-667-31 INDUCTOR 22UH
<TRANSISTOR>
Q704 8-729-326-11 TRANSISTOR 2SC2611
Q705 8-729-326-11 TRANSISTOR 2SC2611
Q706 8-729-326-11 TRANSISTOR 2SC2611
Q707 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
Q708 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
Q709 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
Q710 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q711 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q712 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
<RESISTOR>
R703 1-249-496-11 CARBON 100K 5% 1/2W
R705 1-216-393-00 METAL OXIDE 2.2 5% 3W
R710 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R711 1-247-762-11 CARBON 6.8K 5% 1/2W
R712 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R713 1-247-762-11 CARBON 6.8K 5% 1/2W
R714 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R715 1-247-762-11 CARBON 6.8K 5% 1/2W
R719 1-215-480-00 METAL 300K 1% 1/4W
R720 1-249-923-11 CARBON 1K 5% 1/4W
R721 1-215-489-00 METAL 680K 1% 1/4W
R722 1-249-923-11 CARBON 1K 5% 1/4W
