– 53 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
KV-G21MW3/G21QW3
RM-869
R723 1-215-479-00 METAL 270K 1% 1/4W
R724 1-249-923-11 CARBON 1K 5% 1/4W
R725 1-249-419-11 CARBON 1.5K 5% 1/4W
R726 1-249-419-11 CARBON 1.5K 5% 1/4W
R727 1-249-419-11 CARBON 1.5K 5% 1/4W
R728 1-249-407-11 CARBON 150 5% 1/4W
R729 1-249-408-11 CARBON 180 5% 1/4W
R730 1-249-408-11 CARBON 180 5% 1/4W
R731 1-249-399-11 CARBON 33 5% 1/4W
R732 1-249-399-11 CARBON 33 5% 1/4W
R733 1-249-399-11 CARBON 33 5% 1/4W
R734 1-247-739-11 CARBON 100 5% 1/2W
R738 1-247-807-31 CARBON 100 5% 1/4W
R739 1-247-807-31 CARBON 100 5% 1/4W
R740 1-247-807-31 CARBON 100 5% 1/4W
R755 1-249-418-11 CARBON 1.2K 5% 1/4W
R756 1-249-418-11 CARBON 1.2K 5% 1/4W
R757 1-249-418-11 CARBON 1.2K 5% 1/4W
******************************************************************
MISCELLANEOUS
*****************
! 1-409-942-11 COIL, DEMAGNETIZATION
1-452-032-00 MAGNET,DISC
1-452-277-00 MAGNET, BMC
1-505-740-11 SPEAKER (5X9CM)
1-473-159-21 CAP ASSY, HIGH-VOLTAGE
! 1-574-062-11 CORD, POWER (WITH CONNECTOR) 2.5A/250V
1-900-212-58 LEAD ASSY, FOCUS
C
1-501-372-81 ANTENNA, TELESCOPIC
! 8-451-280-33 DEFLECTION YOKE (Y21PXA2)
! 8-738-774-05 PICTURE TUBE (21PXD(SDS)(SD-169/IBR))
*****************************************************************
ACCESSORIES AND PACKING MATERIALS
***************************************
A-1028-509-A PACKING GROUP (SET) (KV-G21MW3)
A-1028-508-A PACKING GROUP (SET) (KV-G21QW3)
3-701-910-00 SCREW, SPECIAL (DIA. 3.8X20)
* 4-063-809-01 INDIVIDUAL CARTON
* 4-063-798-01 CUSHION (UPPER) (ASSY)
* 4-063-804-01 CUSHION (LEFT UPPER)
* 4-063-805-01 CUSHION (RIGHT UPPER)
* 4-063-799-01 CUSHION (LOWER) (ASSY)
* 4-063-797-01 CUSHION (RIGHT LOWER)
* 4-063-806-01 CUSHION (LEFT LOWER)
* 4-395-957-01 BAG, PROTECTION
4-076-975-11 MANUAL, INSTRUCTION
4-392-003-11 BAND, HOLD
4-392-004-11 CLIP
*****************************************************************
REMOTE COMMANDER
**********************
1-475-358-11 REMOTE COMMANDER (RM-869)
9-939-697-01 BATTERY COVER, REMOTE COMMANDER
