Sony Trinitron Multiscan CPD-1302 - Page 29

CPD-1302
IBAI
Ref.No. Part No. Descri pt ion
Remark IRef.No. Part No.
Description
Remark
--1--
Q3001
8-729-178-54 TRANSISTOR 2SC2785
1 R272
1-247-849-00
CARBON
5.6K 5~
1/6W
Q3002
8-729-117-54
TRANSISTOR 2SAl175
1 R280
1-247-823-00
CARBON
470 5~
1/6W
1 R281
1-249-425-11 CARBON
4.7K
5~ 1/6W
RESISTOR
1 R282 1-216-471-11
METAL OXIDE
27 5~
3W
F
1 R283 1-249-417-11
CARBON
1K
5% 1/6W
R200
1-247-839-00 CARBON
2.2K 5~ 1/6W
1
R207
1-249-425-11 CARBON
4.7K 5% 1/6W
1
R284
1-249-417-11
CARBON 1K
5%
1/6W
R211
1-247 -804 -00
CARBON
75
5%
1/6W
1
R289
1-247-853-00
CARBON
8.2K
5% 1/6W
R212
1-249-434-11 CARBON 27K
5% l/6W
R290
1-247-853-00
CARBON
8.2K
5% 1/6W
R213
1-249-429-11
CARBON
10K
5% 1/6W
R291
1-249-437-11
CARBON 47K
5%
1/6W
R292
1-249-405-11
CARBON 100
5%
1/6W
R214
1-247-849-00 CARBON
5.6K 5~ 1/6W
R215
1-249-429-11 CARBON
10K 5% 1/6W
R293
1-249-417-11 CARBON
1K 5~
1/6W
R216
1-249-417-11 CARBON 1K
5% 1/6W
R294
1-249-440-11
CARBON
82K
5% 1/6W
R217
1-249-419-11 CARBON
1.5K 5% 1/6W
R295
1-214-753-00 METAL
10K
1% 1/4W
R219
1-249-405-11 CARBON
100 5~
1/6W
R296
1-215-445-00 METAL
10K
It 1/6W
R297
1-249-429-11
CARBON
10K 5~
1/6W
R220
1-249-429-11 CARBON 10K
5% 1/6W
R221
1-247-804-00
CARBON
75 5% 1/6W
R298
1-249-433-11
CARBON 22K
5% 1/6W
R222 1-249-434-11 CARBON
27K 5% 1/6W
R299
1-249-429-11
CARBON 10K
5~ 1/6W
R223
1-249-429-11
·CARBON
10K
5% 1/6W
R301
1-215-473-00 METAL
150K
1~ 1/6W
R224
1-247-849-00 CARBON
5.6K 5~ 1/6W
R302
1-215-464-00
METAL
62K 1~
1/6W
R303
1-202-727-00 SOLID
4.7M 10% 1/2W
R225
1-249-429-11 CARBON 10K
5% 1/6W
R226 1-249-417-11 CARBON 1K
5% l/6W
R304
1-249-437 -11 CARBON
47K 5%
1/6W
R227
1-249-419-11
CARBON
1.5K 5% 1/6W
R305
1-249-437 -11
CARBON 47K
5% 1/6W
R229
1-249-405-11 CARBON 100 5%
1/6W
R306
1-247-725-11
CARBON 10K
5%
1/4W
R231
1-247-804-00 CARBON 75
5% 1/6W
R307
1-249-429-11 CARBON
10K 5% 1/6W
R308
1-249-429-11 CARBON 10K
5% 1/6W
R232
1-249-434-11 CARBON 27K
5% 1/6W
R233
1-249-429-11 CARBON
10K
5% 1/6W
R309
1-249-440-11 CARBON
82K 5~ 1/6W
R234
1-247-849-00 CARBON 5.6K 5%
1/6W R310
1-247-721-11 CARBON
4.7K 5~
1/4W
R235
1-249-429-11 CARBON 10K
5% 1/6W
R311
1-249-425-11 CARBON
4.7K 5% 1/6W
R236
1-249-417-11 CARBON 1K
5% 1/6W
R312
1-249-433-11
CARBON 22K
5% 1/6W
R313 1-247-870-00
CARBON 43K 5%
1/6W
R237
1-249-419-11 CARBON
1.5K 5% l/6W
R239
1-249-405-11 CARBON 100 5% 1/6W
R314
1-249-433-11
CARBON 22K
5% 1/6W
R240
1-247-851-00 CARBON 6.8K
5% 1/6W R315
1-247-862-00
CARBON 20K
5% 1/6W
R241
1-247 -839 -00 CARBON
2.2K 5% 1/6W R316
1-247 -869 -00 CARBON
39K 5% 1/6W
R242
1-247-815-00
CARBON 220 5% l/6W R317
1-247 -82 3-00 CARBON 470
5% 1/6W
R318
1-249-433-11 CARBON 22K 5%
1/6W
R243
1-249-434-11
CARBON
27K.
5% 1/6W
R244
1-247-891-00 CARBON 330K 5% 1/6W
R319
1-249-435-11 CARBON 33K
5% 1/6W
R245
1-249-414-11 CARBON 560
5%
1/6W
R320
1-249-429-11 CARBON 10K 5%
1/6W
R246
1-247-823-00 CARBON 470
5% 1/6W R321
1-249-429-11 CARBON 10K 5%
1/6W
R247
1-249-437 -11 CARBON 47K 5% 1/6W
R322
1-247-881-00
CARBON
120K
5% 1/6W
R323
1-249-423-11 CARBON 3.3K 5% 1/6W
R249
1-249-429-11 CARBON 10K
5% 1/6W
R250
1-249-429-11
CARBON 10K 5% 1/6W
R324
1-247-874-00 CARBON
62K
5%
1/6W
R251
1-249-429-11 CARBON 10K
5%
1/6W
R325
1-249-397-11 CARBON
22 5% 1/6W
F
R252
1-247-711-11 CARBON
680
5% 1/4W
R326
1-249-425-11 CARBON 4.7K 5%
1/6W
R253
1-247-895-00 CARBON 470K 5% 1/6W
R327
1-247-881-00
CARBON
120K
5% 1/6W
R328 1-247-869-00 CARBON
39K 5% 1/6W
R254
1-249-433-11 CARBON 22K 5% 1/6W
R255
1-247 -839 -00
CARBON 2.2K 5% 1/6W
R329
1-249-422-11 CARBON 2.7K
5%
1/6W
R256
1-247-711-11
CARBON 680 5% 1/4W
R330
1-247-891-00 CARBON 330K
5% 1/6W
R257
1-249-429-11
CARBON 10K 5% 1/6W R331
1-247-721-11
CARBON 4.7K 5%
1/4W
R258
1-247-881-00 CARBON 120K 5% 1/6W
R332
1-249-433-11 CARBON
22K
5%
l/6W
R333 1-247-857-00 CARBON 12K 5%
1/6W
R259
1-249-433-11 CARBON 22K 5% 1/6W
R260
1-249-405-11 CARBON 100 5% 1/6W R334
1-247-875-00
CARBON 68K 5%
1/6\01
R261
1-249-422-11 CARBON 2.7K 5% 1/6W
R335
1-249-429-11 CARBON 10K 5% 1/6W
R262
1-249-405-11
CARBON
100
5% 1/6W
R336 1-249-429-11
CARBON
10K
5% 1/6W
