CPD-1302
TABLE
OF
CONTENTS
Section Title
1. SETUP ADJUSTMENTS
1-1. Landing Adjustment . . . . . . . . . . . . . . . . . .
..
3
1-2. Deflection Yoke Neck Adjustment
...........
4
1-3.
G
l
Adjustment
........................
6
1-4. Cut-off Adjustment
.....................
6
1-5. White Balance Adjustment . . . . . . . . . . . . . .
..
6
2.
SAFETY RELATED ADJUSTMENT .
........
7
3. CIRCUIT ADJUSTMENT
3-1. H.CENT, V.CENT Adjustment
..............
10
3-2. Picture Distortion Adjustment
..............
10
3-3. Adjustment
of
Horizontal Delay Sync Pulse
.....
II
3-4. Adjustment
of
Horizontal Oscillation Frequency
..
II
3-5. Horizontal Drive Pulse Width
...............
12
3-6. Vertical Sync Frequency Identification
Circuit.
. .
12
3-7.
+B
Adjustment.
. . . . . . . . . . . . . . . . . . . . . . .
12
Input
a microcomputor (SONY SMC-70) signal.
Note: Micro Floppy Disk
(SOFf)
Part No.
___
_
1.
Input a Micro Floppy Disk
on
SMC-70.
2. Select the pattern signal.
(FI-FS)
3. Select
the
Frequency.
(SHIFT
FI-
SHIFT
Fs
)
SHIFT F-I
Is.734kHz
60Hz
SHIFT F-2 18.4 kHz 60Hz
SHIFT F-3 21.8 kHz 60Hz
SHIFT F-4 25.0 kHz 60Hz
SHIFT F-s 31.5 kHz 60Hz
