Ref .No. Part No. Description
C672
1-162-558-11 CERAMIC
100PF
10~
DIODE
D651
8-719-301-18 DIODE RM2CS
D652
8-719-301-18 DIODE RM2CS
D653 8-719-901-93
DIODE Vl9E
D654
8-719-901-93 DIODE V19E
D655
8-719-302 -00
DIODE RU-2M
D656
8-719-500-25
DIODE D5KC20RH
D657
8-719-302 -00 DIODE RU-2M
D658
8-719-302-00 DIODE RU-2M
D659
8-719-982 -04 DIODE ERB81-004
D660 8-719-982 -04
DIODE ERB81-004
D661
8-719-982-04
DIODE ERB81-004
D662
8-719-982 -04
DIODE ERB81-004
D663
8-719-982-04
DIODE ERB81-004
~664
8-719-302 -00
DIODE RU-2M
665
8-719-302 -00
DIODE RU-2M
D666
8-719-302 -00 DIODE RU-2M
D667
8-719-302-00
DIODE RU-2M
D668
8-719-302 -00
DIODE RU-2M
D669
8-719-901-24
THYRISTOR CSM2A4AI0
D670
8-719-102-62
DIODE RD4.3E-N2
D671
8-719-103-06 DIODE RDI3E-N2
D672
8-719-103-06
DIODE RDI3E-N2
D673
8-719-302-00 DIODE RU-2M
D674
8-719-302-00
DIODE RU-2M
D675
8-719-302 -00
DIODE RU-2M
D676
8-719-302 -00
DIODE RU-2M
D677
8-719-302-00 DIODE RU-2M
D678
8-719-901-93
DIODE V19E
D679
8-719-901-93
DIODE V19E
CONNECTOR
Gl
*1-508-765-00
3P PlUG (M)
G2
*1-564-353-00 PLUG, CONNECTOR (2.5MM)
2P
G3 *1-508-766-00 4P PLUG (M)
G4
*1-508-767-00 5P PlUG
G5 *1-508-765-00 3P PLUG (M)
MODULE
IC651 1-235-449-11
POWER MODULE
( DM-19)
TRANSISTOR
0651
8-729-902-41 TRANSISTOR 2SC3318
0652 8-729-902-41
TRANSISTOR 2SC3318
0653 8-729-177 -113
TRANSISTOR 2SD774
0654 8-729-177 -43 TRANSISTOR 2SD774
0655 8-729-117 -54
TRANSISTOR 2SA1175
0656
8-729-117 -54
TRANSISTOR 2SA1175
0657 8-729-178-54 TRANSISTOR 2SC2785
CPD-1302
@]~
Remark IRef.No. Part No.
Description
Remark
--1--
2KV
1
1
1
1
1
1
1
1
1
1
1
1
RESISTOR
R651
1-202-842-51
SOLID
220K
1/2W
R652
1-202 -842- 51
SOLID
220K
1/2W
R653
1-202-842-'!il
SOtID 220K
1/2W
R654
1-217 -418-00
FUSIBLE
0.47 10~
1/2W F
R655
1-217-418-00
FUSIBLE
0.47
10~
1/2W F
R656 1-216-374-00
METAt OXIDE
2.7 5~ 2W
F
R657
1-216-374-00
METAL OXIDE
2.7 5~ 2W
F
R658
1-247-717-11
CARBON
2.2K 5~
1/4W
R659
1-247-700-11
CARBON
100 5~
l/4W
R660
1-215-468-00
METAL
91K
1%
1/6W
R661
1-215-449-00
METAL 15K
1%
1/6W
R662
1-247-719-11
CARBON
3.3K 5%
1/4W
R663
1-247-717-11
CARBON
2.2K 5%
1/4W
R664
1-215-469-00
METAL
lOOK
1%
1/6W
R665
1-215-451-00
METAL
18K
1% 1/6W
R666
1-215-467-00
METAL
82K 1~
1/6W
R667 1-215-451-00
METAL 18K
1%
1/6W
R668
1-247-719-11
CARBON
3.3K 5%
l/4W
R669
1-249-441-11
CARBON
lOOK 5%
1/6W
R671
1-249-381-11
CARBON 1
5% 1/6W
F
R672
1-202-842-51
SOUD
220K
1/2W
R673
1-247-717-11
CARBON
2.2K 5%
1/4W
R674
1-249-429-11
CARBON 10K 5~
1/6W
TRANSFORMER
T651
il-421-704-11
CDT
T652
1-421-886-11 PIT
T653 &1-421-888-11
PRT
T654
&1-421-889-11
PRT
T655
&1-421-889-11
PRT
T656 &1-421-885-11
COT
T657 &1-421-887-11
PHT
*****************************kkkJdtkkk**************** *********
*A-1330-716-A CB BOARD, COMPtETE
******************
1-526-762-00 SOCKET, CRT
NEON LAMP
NL701 1-519-371-11 LAMP, NEON
NL702 1-519-371-11 LAMP, NEON
NL703 1-519-371-11 LAMP, NEON
RESISTOR
R701 1-202-719-00 SOLID
1M 10% 1/2W
R706 1-202-824-00 SOUD
3.3K 1/2W
VARIABLE RESISTOR
RV703 1-230-798-11 RES, ADJ, METAL GLAZE 90M
: .......... : ......................................................... .
The components identified
by shading and mark ftare
critical for safety.
Replace only with part
number speci fied.
Les composants identifies par
: un: ~rame et une marqu.eftso~t :
: Crltlques pour la seCUrlte. :
Ne 1 es rempl acer que par'
une pi fce portant 1 e numero;.: i:
specifie. :rYl
..•..•.•..••••...... < ......... : ............. :~:::,:,:;.:::.:.::lmrK:wr:&'.t'l~:
- 47-
