isillg 6n-Screen Menus .. · .••.. . ·. · •
(ID REMOTE (RS-232C) menu
Select one out of following three modes.
REMOTE OFF:
You
can adjust settings and controls by the buttons
and controls on
the front panel.
The RS-232C connector does not function.
REMOTE ONLY:
You
can adjust settings and controls through the
RS-2:12C connector.
Buttons and controls on the front panel, except the
menu operation ones, do not functin.
REMOTE & LOCAL:
You can adjust settings and controls both through the
RS-232C connector and the front panel buttons.
Controls on the front panel do not function.
[REMOTE OFF]
[ill LANGUAGE menu
You can select the language used for on-screen menus
from the following five languages (English, German.
French, Italian, Spanish). [ENGLISH!
\TI] AUTO ADJUST screen
Select the color bar signal (full, SMPTE, EIA) and press
the ENTER (SELECT) button to start automatic
adjustment for CHROMA and PHASE. For these
adjustments to be valid, you must select ON in
CHROMA SET UP menu
([ill).
User Service Mocle
The user service mode is useful when adjusting the settings
and controls except
for the above.
To enter the user service mode, press and hold the MENU
(EXIT) button
until the following USER SERVICE I
appears.
To
move to the second page of the mode. select "NEXT
PAGE" and to return to the first page. select "PREVIOUS
PAGE".
12
USER SERVICE 1
., USER COLOR TEMP ADJUST
COLOR SYSTEM O 1SPLAY
358 TRAP FILTER
SPLIT PHASE
NEXT PAGE
USER SERVICE 2
• COMPONENT LEVEL
NTSC SETUP LEVEL
SUB CONTROL
V HOLD
PAEV I OUS PAGE
'I
1
1SELECT 2
El
I
PVM-1453MD
[gj USER COLOR TEl\tP ADJUST menu
T~e value of adjustment in this menu works only when
"'USER" is selected in the COLOR TE'.vlP SELECT
menu
([g]).
ADJUST GAIN:
Adjusts
the color balance (gain) of the USER mode.
ADJUST BIAS:
Adjusts the color balance (bias) of the USER mode.
COLOR TEMP
RANGE:
When you adjust the color temperature in the USER
mode, select a color temperature range before
adjusting ADJUST GAIN and ADJUST BIAS. If the
adjusted color temperature is between 3200K and
5000K, select
.. 3200K-5000K:· If the adjusted color
temperature is between 5000K and l OOOOK. select
"5000K-IOOOOK.'' [5000K-IOOOOK]
~
COLOR SYSTEM DISPLAY menu
Select the color system display mode. In AUTO, the
kind of color system being used appears on the screen
each time you change the signal input. [AUTO]
M 358 TRAP FILTER menu
Color spill or color noise may be eliminated if you
select ON (NTSC signal only).
l'\ormally set it to OFF.
[OFF)
[§I SPLIT PHASE n1enu
When the SPLIT function is acti\'ated. if the lower side
picture (the signal fed through the RGB/COMPONENT
B input connectors) has some discrepancy of location
with the upper side picture, adjust the SPLIT PHASE
menu.
Each time you press the
t( +) button, the lower side
picture moves left.
l~Mti
When the adjustment is made in the menu. the skew
error will occur on the top of the lower side picture.
[§] COMPONENT LEVEL menu
Select the component Je\·el from among three modes.
NIO/SMPTE: for I00/0/100/0 signal
BETA 7.5: for I00/7.5/75/7.5 signal
BETA 0: for 100/0/75/0 signal
[N 10/Sivf PTEJ
[Z] NTSC SETUP LEVEL menu
Select the NTSC setup le\·el from two modes. The 7.5
setup level is mainly used in north America. The O setup
level is mainly used in Japan. l OJ
G]J SUB CONTROL screen
You can finely adjust the controls on the front panel.
CONTRAST, PHASE.
CHRO:-lA and BRIGHT
controls
have clicks at the center of their adjustment
range. You can adjust
the setting of the click position
with this feature.
[ill V HOLD screen
Adjust the vertical hold if the pi..:ture rolb Yertically.
l~Mti
If the rolling of the pi::ture preYents you from watching
the screen, select an input that
ha, nothing connected.
-24-
