75
Additional Information
Input and output
connectors
S video input/output
4-pin mini DIN
Luminance signal: 1 Vp-p,
75 ohms, unbalanced
Chrominance signal: 0.286 Vp-p,
75 ohms, unbalanced
Video input/output
Phono jack, 1 Vp-p, 75 ohms,
unbalanced
Audio input/output
Phono jacks (2: stereo L and R)
327 mV, (at output impedance
47 kilohms) impedance less than
2.2 kilohms
RFU DC OUT
Special minilack, DC 5V
DV input/output
4-pin connector
Headphone jack
Stereo minijack (ø 3.5 mm)
LANC control jack
Stereo mini-minijack (ø 2.5 mm)
MIC jack
Minijack, 0.388 mV low impedance
with 2.5 to 3.0 V DC, output
impedance 6.8 kilohms (ø 3.5 mm)
Stereo type
LCD screen
DCR-TRV203/TRV210/TRV315:
3 inches measured diagonally
2 3/8 × 1 3/4 in. (59.5 × 43.2 mm)
DCR-TRV310:
3.5 inches measured diagonally
2 7/8 × 2 in. (72.4 × 50.4 mm)
Total dot number
DCR-TRV203/TRV210/TRV315:
89,622 (383 × 234)
DCR-TRV310:
105,380 (479 × 220)
General
Power requirements
7.2 V (battery pack)
8.4 V (AC power adaptor)
Average power consumption
(when using the battery pack)
During camera recording using
LCD
DCR-TRV203/TRV210/TRV315:
3.9 W
DCR-TRV310: 4.2 W
Viewfinder
DCR-TRV203/TRV210/TRV310:
3.2 W
DCR-TRV315: 3.1W
Video camera
recorder
System
Video recording system
2 rotary heads
Helical scanning system
Audio recording system
Rotary heads, PCM system
Quantization: 12 bits (Fs 32 kHz,
stereo 1, stereo 2), 16 bits
(Fs 48 kHz, stereo)
Video signal
NTSC color, EIA standards
Recommended cassette
Hi8 video cassette
Recording/playback time (using
120 min. cassette)
1 hours
Fastforward/rewind time (using
120 min. cassette)
Approx. 8 min.
Image device
1/4 inch CCD (Charge Coupled
Device)
Approx. 460,000 pixels
(Effective: Approx. 290,000 pixels)
Lens
Combined power zoom lens
Filter diameter 1 7/16 in. (37 mm)
20× (Optical), 360×
(Digital)
Focal length
5/32 - 2 7/8 in. (3.6 - 72 mm)
When converted to a 35 mm still
camera
1 5/8 - 32 3/8 in. (41 - 820 mm)
Color temperature
Auto
Minimum illumination
1.0 lux (F 1.4)
0 lux (in the NightShot mode)*
* Objects unable to be seen due to
the dark can be shot with
infrared lighting.
Specifications
Operating temperature
32 °F to 104 °F (0 °C to 40 °C)
Storage temperature
–4 °F to +140 °F (–20 °C to +60 °C)
Dimensions (Approx.)
DCR-TRV203/TRV210/TRV310:
4 3/8 × 4 1/4 × 8 5/8 in.
(108 × 107 × 217 mm) (w/h/d)
DCR-TRV315:
4 3/8 × 4 1/4 × 7 3/4 in.
(108 × 106 × 195 mm) (w/h/d)
Mass (approx.)
DCR-TRV203/TRV210/TRV315:
2 lb (930 g)
DCR-TRV310:
2 lb 1 oz (960 g)
excluding the battery pack, lithium
battery, cassette and shoulder
strap
2 lb 6 oz (1.1 kg)
including the battery pack
NP-F330, lithium battery CR2025,
120 min. cassette and shoulder
strap
Supplied accessories
See page 7.
AC power adaptor
Power requirements
100 - 240 V AC, 50/60 Hz
Power consumption
23 W
Output voltage
DC OUT: 8.4 V, 1.5 A in operating
mode
Operating temperature
32 °F to 104 °F (0 °C to 40 °C)
Storage temperature
–4 °F to +140 °F (–20 °C to +60 °C)
Dimensions (approx.)
5 × 1 9/16 × 2 1/2 in.
(125 × 39 × 62 mm) (w/h/d)
excluding projecting parts
Mass (approx.)
9.8 oz (280 g)
excluding power cord
Cord length (approx.)
AC power cord: 6.6 feet (2 m)
Connecting cord: 5.2 feet (1.6 m)
Design and specifications are
subject to change without notice.
