1-18
VPL-CX20/CS20
1-3-19. Lamp
1-3-20. Precaution During Lamp and Concave Lens
m
. Install the lens concave after installing the lamp.
(The lamp spring cannot be secured if the lens concave spring is installed first.)
. When the lamp is removed, the lamp cover and the net (lamp) are also removed at the same time.
When installing a new lamp, be sure not to loose the two parts or leave them unattached.
1
Three lamp springs
2
Lamp
2
Slit
1
Insert the net lamp into the slit.
3
Two dowels
4
Lamp cover
Lamp box
To Next Page
