Sony VPL-CX20 - Disassembly Procedures Overview

1-2
VPL-CX20/CS20
1-3. Disassembly
1-3-1. Top Panel
1-3-2. C Board
How to Replace the Parts
When the Lamp Exploded
1-3-3. Optics Unit
1-3-4. Prism Black Assembly
1-3-5. Incidence Polarizer Assembly 1-3-6. PS Assembly
1-3-9. Lamp Power Supply
1-3-7. Adjustor Unit
D
B
C
A
1-3-8. D.C. Fan (For Lamp)
