6-1
VPL-CX20/CS20
6-1
Section 6
Diagrams
Index
Board Name Function Page
C Video Signal Processor 6-3
H Panel Switch & LED 6-17
L Logo LED 6-18
NF SIRCS Receiver 6-18
NR SIRCS Receiver 6-18
U Lamp Cover Switch 6-18
V Angle Detect 6-18
F AC Inlet 6-19
GA Power Supply Control 6-20
GB DC-DC Converter 6-23
