6-2

VPL-S900E, VPL-S900M, VPL-S900U

Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK

* A-1135-988-A BA BOARD, COMPLETE

**********************

C2001 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2002 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2003 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2004 1-126-205-11 ELECT CHIP 47µF 20% 6.3V

C2005 1-126-205-11 ELECT CHIP 47µF 20% 6.3V

C2006 1-126-205-11 ELECT CHIP 47µF 20% 6.3V

C2007 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2008 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2009 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2010 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2011 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2012 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2013 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2014 1-126-205-11 ELECT CHIP 47µF 20% 6.3V

C2015 1-126-205-11 ELECT CHIP 47µF 20% 6.3V

C2016 1-126-205-11 ELECT CHIP 47µF 20% 6.3V

C2018 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2019 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2020 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2021 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2022 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2023 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2024 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2025 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2026 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2027 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2028 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2033 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2034 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2037 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2038 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C2039 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2040 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2041 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2042 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2043 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2044 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2045 1-164-182-11 CERAMIC CHIP 0.0033µF10% 50V

C2046 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2047 1-164-182-11 CERAMIC CHIP 0.0033µF10% 50V

C2048 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2049 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2050 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2051 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2052 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2054 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2055 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2056 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2057 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2058 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V

C2059 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2060 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2061 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2062 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2063 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2065 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2069 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2070 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2071 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2078 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2079 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2080 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2081 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2082 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2083 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2084 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2085 1-124-779-00 ELECT CHIP 10µF 20% 16V

C2086 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2087 1-124-779-00 ELECT CHIP 10µF 20% 16V

C2089 1-163-233-11 CERAMIC CHIP 18PF 5% 50V

C2090 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2091 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2092 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2093 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2094 1-163-239-11 CERAMIC CHIP 33PF 5% 50V

C2099 1-126-204-11 ELECT CHIP 47µF 20% 16V

C2106 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2116 1-124-779-00 ELECT CHIP 10µF 20% 16V

C2117 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2118 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2119 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2120 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2121 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2122 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2123 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2125 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2126 1-163-229-11 CERAMIC CHIP 12PF 5% 50V

C2127 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2128 1-117-681-11 ELECT CHIP 100µF 20% 16V

C2129 1-163-229-11 CERAMIC CHIP 12PF 5% 50V

C2130 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2131 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2132 1-163-222-11 CERAMIC CHIP 5PF 0.25PF50V

C2134 1-163-089-00 CERAMIC CHIP 6PF 0.5PF 50V

C2135 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2136 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2137 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2138 1-164-182-11 CERAMIC CHIP 0.0033µF10% 50V

C2139 1-164-346-11 CERAMIC CHIP 1µF 16V

C2140 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2141 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2142 1-107-686-11 TANTAL. CHIP 4.7µF 20% 16V

C2143 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V

C2144 1-126-941-11 ELECT 470µF 20% 25V

C2145 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2146 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C2147 1-163-017-00 CERAMIC CHIP 0.0047µF10% 50V

C2148 1-107-682-11 CERAMIC CHIP 1µF 10% 16V

C2154 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
