Sony VPL-S900E - BA BOARD; BA Board ICs, Coils, and Transistors; BA Board Resistors (R2001-R2506)

6-4
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
<IC>
IC2001 8-752-072-94 IC CXA1875AM-T4
IC2002 8-759-522-86 IC M52755FP-TP
IC2003 8-752-073-52 IC CXA2016S
IC2004 8-752-073-52 IC CXA2016S
IC2005 8-759-491-93 IC EL4332CS-TE2
IC2006 8-759-272-90 IC 74VHC240SJX
IC2007 8-759-272-90 IC 74VHC240SJX
IC2008 8-759-387-75 IC TC7W00F(TE12R)
IC2012 8-759-492-19 IC MM1231XFBE
IC2014 8-759-335-57 IC MM1112XF
IC2015 8-759-295-47 IC TDA9141-N2C
IC2016 8-759-565-20 IC TDA4665T/V5-118
IC2017 8-759-335-57 IC MM1112XF
IC2018 8-752-070-54 IC CXA1839Q-T6
IC2022 8-752-072-94 IC CXA1875AM-T4
IC2025 8-759-524-85 IC TC7W240FU(TE12R)
IC2026 8-759-432-78 IC MM1111XFBE
IC2027 8-759-186-43 IC TC74VHC123AF
IC2301 8-752-372-78 IC CXD2024AQ
IC2302 8-759-711-62 IC NJM2240M
IC2501 8-759-572-04 IC TDA9178T/N1.118
<COIL>
L2001 1-410-671-31 INDUCTOR 47µH
L2011 1-414-235-22 INDUCTOR CHIP 0µH
L2012 1-414-235-22 INDUCTOR CHIP 0µH
L2013 1-414-235-22 INDUCTOR CHIP 0µH
L2014 1-414-235-22 INDUCTOR CHIP 0µH
L2015 1-412-363-21 FERRITE 0µH
L2016 1-412-363-21 FERRITE 0µH
L2017 1-412-363-21 FERRITE 0µH
L2023 1-414-235-22 INDUCTOR CHIP 0µH
L2024 1-414-235-22 INDUCTOR CHIP 0µH
L2025 1-414-235-22 INDUCTOR CHIP 0µH
L2026 1-414-235-22 INDUCTOR CHIP 0µH
L2027 1-412-796-41 INDUCTOR 47µH
L2028 1-414-235-22 INDUCTOR CHIP 0µH
L2029 1-414-235-22 INDUCTOR CHIP 0µH
L2301 1-414-267-11 INDUCTOR 10µH
L2302 1-414-267-11 INDUCTOR 10µH
L2303 1-414-267-11 INDUCTOR 10µH
<TRANSISTOR>
Q2001 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2002 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2003 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2004 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2005 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2006 8-729-216-22 TRANSISTOR 2SA1162-G
Q2007 8-729-216-22 TRANSISTOR 2SA1162-G
Q2008 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2009 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2010 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2011 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2012 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2013 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2014 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2015 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2016 8-729-216-22 TRANSISTOR 2SA1162-G
Q2017 8-729-216-22 TRANSISTOR 2SA1162-G
Q2018 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2019 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2020 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2021 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2022 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2023 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2024 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2025 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2026 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2027 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2028 8-729-107-31 TRANSISTOR 2SC3545-T43
Q2029 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2030 8-729-216-22 TRANSISTOR 2SA1162-G
Q2031 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2032 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2035 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2036 8-729-216-22 TRANSISTOR 2SA1162-G
Q2037 8-729-216-22 TRANSISTOR 2SA1162-G
Q2038 8-729-216-22 TRANSISTOR 2SA1162-G
Q2039 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2040 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2041 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2302 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q2303 8-729-216-22 TRANSISTOR 2SA1162-G
Q2304 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2305 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
R2001 1-216-295-91 SHORT 0
R2002 1-216-295-91 SHORT 0
R2003 1-216-295-91 SHORT 0
R2004 1-216-295-91 SHORT 0
R2005 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2006 1-216-039-00 RES,CHIP 390 5% 1/10W
R2007 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2008 1-216-039-00 RES,CHIP 390 5% 1/10W
R2009 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R2010 1-216-295-91 SHORT 0
R2011 1-216-295-91 SHORT 0
R2012 1-216-295-91 SHORT 0
R2013 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R2014 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R2015 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2016 1-216-025-91 RES,CHIP 100 5% 1/10W
R2017 1-216-025-91 RES,CHIP 100 5% 1/10W
R2018 1-216-025-91 RES,CHIP 100 5% 1/10W
R2019 1-216-025-91 RES,CHIP 100 5% 1/10W
R2020 1-216-025-91 RES,CHIP 100 5% 1/10W
R2021 1-216-025-91 RES,CHIP 100 5% 1/10W
R2022 1-216-085-00 RES,CHIP 33K 5% 1/10W
BA
