Sony VPL-S900E - BAA BB BOARD; BAA BB Board Resistors

6-9
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
C3124 1-115-156-11 CERAMIC CHIP1µF 10V
C3125 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3126 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3128 1-126-204-21 ELECT 1µF 16V
C3129 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3130 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3131 1-115-156-11 CERAMIC CHIP1µF 10V
C3132 1-115-156-11 CERAMIC CHIP1µF 10V
C3133 1-115-156-11 CERAMIC CHIP1µF 10V
C3134 1-115-156-11 CERAMIC CHIP1µF 10V
C3135 1-115-156-11 CERAMIC CHIP1µF 10V
C3136 1-115-156-11 CERAMIC CHIP1µF 10V
C3137 1-115-156-11 CERAMIC CHIP1µF 10V
C3139 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3140 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3142 1-126-204-21 ELECT 1µF 16V
C3143 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3144 1-126-394-11 ELECT CHIP 10µF 20% 16V
C3145 1-126-394-11 ELECT CHIP 10µF 20% 16V
C3147 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3148 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3151 1-115-156-11 CERAMIC CHIP1µF 10V
C3155 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3156 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3157 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3159 1-115-156-11 CERAMIC CHIP1µF 10V
C3160 1-115-156-11 CERAMIC CHIP1µF 10V
C3161 1-115-156-11 CERAMIC CHIP1µF 10V
C3162 1-115-156-11 CERAMIC CHIP1µF 10V
C3164 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3166 1-164-156-11 CERAMIC CHIP0.1µF 25V
C3168 1-115-156-11 CERAMIC CHIP1µF 10V
C3170 1-115-156-11 CERAMIC CHIP1µF 10V
C3172 1-115-156-11 CERAMIC CHIP1µF 10V
C3173 1-115-156-11 CERAMIC CHIP1µF 10V
C3174 1-115-156-11 CERAMIC CHIP1µF 10V
C3184 1-164-156-11 CERAMIC CHIP0.1µF 25V
<CONNECTOR>
CN3001 1-760-388-11 PIN, CONNECTOR (SMD)9P
CN3004 1-764-007-11 PIN, CONNECTOR (SMD)12P
CN3005 1-573-806-21 PIN, CONNECTOR (1.5MM)(SMD)6P
<DIODE>
D3001 8-719-988-62 DIODE 1SS355
D3002 8-719-988-62 DIODE 1SS355
D3003 8-719-988-62 DIODE 1SS355
D3004 8-719-988-62 DIODE 1SS355
D3005 8-719-988-62 DIODE 1SS355
D3006 8-719-988-62 DIODE 1SS355
D3007 8-719-988-62 DIODE 1SS355
D3012 8-719-985-01 DIODE LM385M-1.2
<FILTER>
FL3001 1-239-898-22 FILTER, EMI (SMD)
FL3002 1-239-898-22 FILTER, EMI (SMD)
FL3003 1-239-897-12 FILTER, EMI (SMD)
FL3006 1-239-897-12 FILTER, EMI (SMD)
FL3007 1-239-897-12 FILTER, EMI (SMD)
FL3008 1-239-897-12 FILTER, EMI (SMD)
FL3009 1-239-897-12 FILTER, EMI (SMD)
FL3010 1-239-897-12 FILTER, EMI (SMD)
<IC>
IC3003 8-759-473-74 IC SN74CBTD3306PW-E20
IC3004 8-759-482-35 IC MC100ELT20DR2
IC3005 8-759-524-50 IC TC74VHC541FT (EL)
IC3006 8-759-490-41 IC TC74VHCT541AFT (EL)
IC3007 8-759-464-43 IC CDC339NS
IC3009 8-759-369-85 IC BT121KPJ80
IC3011 8-752-086-22 IC CXA31060-T6
IC3014 8-759-546-24 IC SN74ALVCH162270TE
IC3017 8-752-071-69 IC CXA3026Q
IC3018 8-759-183-52 IC TL431CPK-E1
IC3020 8-752-071-69 IC CXA3026Q
IC3021 8-759-183-52 IC TL431CPK-E1
IC3022 8-759-546-24 IC SN74ALVCH162270TE
IC3026 8-759-549-39 IC IP00C901
IC3028 8-752-071-69 IC CXA3026Q
IC3029 8-759-183-52 IC TL431CPK-E1
IC3031 8-759-183-52 IC TL431CPK-E1
IC3032 8-759-531-34 IC MB81G83222-010PQ-A
IC3033 8-759-546-23 IC IP00C702
IC3037 8-759-531-34 IC MB81G83222-010PQ-A
IC3038 8-759-546-23 IC IP00C702
IC3039 8-759-531-34 IC MB81G83222-010PQ-A
IC3040 8-759-546-23 IC IP00C702
IC3041 8-759-510-71 IC BA10358F-E2
IC3042 8-759-475-39 IC TC74LCX74FT (EL)
IC3045 8-759-549-98 IC TC7SH14FU
IC3046 8-759-475-29 IC TC74LCX574F (EL)
IC3047 8-759-475-29 IC TC74LCX574F (EL)
<RESISTOR>
R3001 1-216-815-11 RES, CHIP 330 5% 1/16W
R3005 1-216-801-11 RES, CHIP 22 5% 1/16W
R3006 1-216-815-11 RES, CHIP 330 5% 1/16W
R3008 1-216-815-11 RES, CHIP 330 5% 1/16W
R3010 1-216-815-11 RES, CHIP 330 5% 1/16W
R3012 1-216-815-11 RES, CHIP 330 5% 1/16W
R3014 1-216-815-11 RES, CHIP 330 5% 1/16W
R3017 1-218-697-11 METAL CHIP 1.6K 0.50%1/16W
R3018 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R3019 1-216-017-91 RES, CHIP 47 5% 1/10W
R3020 1-216-801-11 RES, CHIP 22 5% 1/16W
R3022 1-216-648-11 METAL CHIP 750 0.50%1/10W
R3023 1-216-648-11 METAL CHIP 750 0.50%1/10W
R3024 1-216-624-11 METAL CHIP 75 0.50%1/10W
R3026 1-216-017-91 RES, CHIP 47 5% 1/10W
R3028 1-216-648-11 METAL CHIP 750 0.50%1/10W
R3029 1-216-648-11 METAL CHIP 750 0.50%1/10W
R3030 1-216-624-11 METAL CHIP 75 0.50%1/10W
R3032 1-216-801-11 RES, CHIP 22 5% 1/16W
BB
