6-11

VPL-S900E, VPL-S900M, VPL-S900U

Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK

C5022 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V

C5023 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V

C5024 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5027 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5028 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5029 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5031 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5033 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5034 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5035 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5037 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5038 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5040 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5101 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5102 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5103 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5106 1-163-251-11 CERAMIC CHIP 100PF 5% 50V

C5108 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5109 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5110 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5111 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5112 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5113 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5114 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5115 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5116 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5117 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5118 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5119 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5121 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5123 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5124 1-109-994-11 CERAMIC CHIP 2.2µF 10% 10V

C5125 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5126 1-109-994-11 CERAMIC CHIP 2.2µF 10% 10V

C5127 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5128 1-109-994-11 CERAMIC CHIP 2.2µF 10% 10V

C5129 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5130 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5131 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5133 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5134 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5135 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5136 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5137 1-164-346-11 CERAMIC CHIP 1µF 16V

C5138 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5139 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5140 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5141 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5142 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5143 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5144 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5145 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5148 1-164-346-11 CERAMIC CHIP 1µF 16V

C5156 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5157 1-164-346-11 CERAMIC CHIP 1µF 16V

C5161 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5169 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5170 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5172 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5201 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5202 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5217 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5218 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5222 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5223 1-128-400-11 ELECT CHIP 47µF 20% 25V

C5227 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5228 1-117-681-11 ELECT CHIP 100µF 20% 16V

C5229 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5301 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5302 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5306 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5307 1-128-400-11 ELECT CHIP 47µF 20% 25V

C5311 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5312 1-117-681-11 ELECT CHIP 100µF 20% 16V

C5313 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5317 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5318 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5322 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5323 1-128-400-11 ELECT CHIP 47µF 20% 25V

C5327 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5328 1-117-681-11 ELECT CHIP 100µF 20% 16V

C5329 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5401 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5402 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C5403 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5404 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5405 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5406 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5415 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5416 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5601 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5602 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5603 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5604 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5605 1-126-204-11 ELECT CHIP 47µF 20% 16V

C5606 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5607 1-163-243-11 CERAMIC CHIP 47PF 5% 50V

C5608 1-164-690-91 CERAMIC CHIP 0.0022µF5% 50V

C5609 1-164-690-91 CERAMIC CHIP 0.0022µF5% 50V

C5611 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5612 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5613 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5614 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C5615 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

CN5001 * 1-580-057-11 PIN, CONNECTOR (SMD) 4P

CN5002 * 1-764-007-11 PIN, CONNECTOR (SMD) 12P

CN5003 * 1-764-177-11 PIN, CONNECTOR (SMD)(1.5MM) 7P

CN5006 * 1-580-056-21 PIN, CONNECTOR (SMD) 3P

CN5007 * 1-764-643-21 PIN, CONNECTOR (SMD) 11P

CN5008 * 1-569-481-11 CONNECTOR, FPC 30P
