Sony VPL-S900E - C F GA; C Board Components (F & GA Sections)

6-15
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
R5501 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5502 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R5503 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R5504 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R5515 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R5516 1-216-049-91 RES,CHIP 1K 5% 1/10W
R5528 1-216-049-91 RES,CHIP 1K 5% 1/10W
R5532 1-216-025-91 RES,CHIP 100 5% 1/10W
R5533 1-216-025-91 RES,CHIP 100 5% 1/10W
R5608 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R5613 1-216-650-11 METAL CHIP 910 0.50% 1/10W
R5614 1-216-650-11 METAL CHIP 910 0.50% 1/10W
R5615 1-216-650-11 METAL CHIP 910 0.50% 1/10W
R5616 1-216-017-91 RES,CHIP 47 5% 1/10W
R5617 1-216-017-91 RES,CHIP 47 5% 1/10W
R5618 1-216-017-91 RES,CHIP 47 5% 1/10W
R5619 1-216-684-91 METAL CHIP 24K 0.50% 1/10W
R5620 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R5621 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5622 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5623 1-216-085-00 RES,CHIP 33K 5% 1/10W
R5624 1-216-664-11 METAL CHIP 3.6K 0.50% 1/10W
R5625 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R5626 1-216-043-91 RES,CHIP 560 5% 1/10W
R5627 1-216-295-91 SHORT 0
R5629 1-216-017-91 RES,CHIP 47 5% 1/10W
R5630 1-216-017-91 RES,CHIP 47 5% 1/10W
R5635 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R5636 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R5637 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R5638 1-216-017-91 RES,CHIP 47 5% 1/10W
R5639 1-216-017-91 RES,CHIP 47 5% 1/10W
R5640 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R5641 1-216-017-91 RES,CHIP 47 5% 1/10W
R5642 1-216-017-91 RES,CHIP 47 5% 1/10W
R5643 1-216-025-91 RES,CHIP 100 5% 1/10W
R5644 1-216-025-91 RES,CHIP 100 5% 1/10W
R5645 1-216-025-91 RES,CHIP 100 5% 1/10W
R5646 1-216-025-91 RES,CHIP 100 5% 1/10W
R5647 1-216-025-91 RES,CHIP 100 5% 1/10W
R5654 1-216-025-91 RES,CHIP 100 5% 1/10W
R5655 1-216-295-91 SHORT 0
R5658 1-216-017-91 RES,CHIP 47 5% 1/10W
<NETWORK RESISTOR>
RB5101 1-233-576-11 RES, CHIP NETWORK 100x4
<THERMISTOR>
TH5001 1-808-656-11 THERMISTOR
TH5002 1-806-715-11 THERMISTOR
<CRYSTAL>
X5001 1-767-347-11 VIBRATOR, CRYSTAL (16MHz)
*****************************************************************
* A-1241-314-A F BOARD, COMPLETE
*********************
1-533-223-11 HOLDER, FUSE (f9001)
* 4-374-846-01 COVER, CAPACITOR, CAP TYPE
<CAPACITOR>
C9001 ! 1-113-912-51 CERAMIC 0.0047µF20% 250V
C9002 ! 1-113-912-51 CERAMIC 0.0047µF20% 250V
C9003 ! 1-113-513-11 FILM 1µF 20% 275V
C9004 ! 1-113-513-11 FILM 1µF 20% 275V
C9005 ! 1-113-912-51 CERAMIC 0.0047µF20% 250V
C9006 ! 1-113-912-51 CERAMIC 0.0047µF20% 250V
<CONNECTOR>
CN9001 * 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN9002 * 1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
<FUSE>
F9001 ! 1-576-233-11 FUSE (H.B.C.)(6.3A/250V)
<FERRITE BEAD>
FB9001 ! 1-410-396-21 INDUCTOR 0.45µH
<COIL>
L9001 ! 1-431-838-11 TRANSFORMER, LINE FILTER
<RESISTOR>
R9001 ! 1-202-882-91 SOLID 560K 20% 1/2W
R9002 ! 1-202-882-91 SOLID 560K 20% 1/2W
<VARISTOR>
VD9001 ! 1-801-073-41 VARISTOR ERZV14D471
*****************************************************************
* A-1316-340-B GA BOARD, COMPLETE
***********************
1-543-923-11 FERRITE 0µH
7-682-147-01 SCREW +P 3X6
7-682-948-01 SCREW +PSW 3X8
C F
GA
